GAN Evaluation Report - Patient BC23122020

Native→Venous Translation Metrics (Generated Venous vs Real Venous)

Targeted Slice 70 - Network-Normalized Analysis (Generated vs Real Venous)

0.746

SSIM Score

0.184

RMSE

0.090

MAE

Average Network-Normalized Metrics Across All Slices (107 slices) - Generated vs Real Venous

0.752

SSIM Score (Avg)

0.154

RMSE (Avg)

0.080

MAE (Avg)

Targeted Slice 70 - HU-Space Analysis (Generated vs Real Venous)

0.746

HU SSIM

184.1

HU RMSE

89.6

HU MAE

Average HU-Space Metrics Across All Slices (107 slices) - Generated vs Real Venous

0.752

HU SSIM (Avg)

154.0

HU RMSE (Avg)

79.6

HU MAE (Avg)

Targeted Slice 70 - Lung Window Analysis (Generated vs Real Venous)

0.570

Lung SSIM

175.9

Lung RMSE

76.4

Lung MAE

Average Lung Window Metrics Across All Slices (107 slices) - Generated vs Real Venous

0.577

Lung SSIM (Avg)

142.2

Lung RMSE (Avg)

65.4

Lung MAE (Avg)

Targeted Slice 70 - Mediastinum Window Analysis (Generated vs Real Venous)

0.680

Mediastinum SSIM

62.6

Mediastinum RMSE

25.7

Mediastinum MAE

Average Mediastinum Window Metrics Across All Slices (107 slices) - Generated vs Real Venous

0.636

Mediastinum SSIM (Avg)

60.4

Mediastinum RMSE (Avg)

27.4

Mediastinum MAE (Avg)

Detailed Per-Slice Metrics

Slice ID	SSIM	RMSE	MAE	HU SSIM	HU RMSE	HU MAE	Lung SSIM	Lung RMSE	Lung MAE	Mediastinum SSIM	Mediastinum RMSE	Mediastinum MAE
BC23122020_slice_0	0.770	0.112	0.062	0.770	112.1	62.0	0.617	89.3	44.7	0.636	56.5	26.5
BC23122020_slice_1	0.771	0.108	0.061	0.771	108.5	60.6	0.613	85.7	43.5	0.632	56.4	26.6
BC23122020_slice_2	0.786	0.105	0.059	0.786	105.2	59.2	0.625	81.8	42.0	0.636	55.0	25.6
BC23122020_slice_3	0.786	0.106	0.060	0.786	106.4	59.9	0.627	83.2	43.0	0.642	55.1	25.5
BC23122020_slice_4	0.786	0.106	0.060	0.786	106.2	60.2	0.625	83.4	43.4	0.642	54.0	24.9
BC23122020_slice_5	0.787	0.107	0.060	0.787	107.1	60.2	0.626	84.1	43.5	0.644	52.8	24.2
BC23122020_slice_6	0.787	0.108	0.061	0.787	107.7	60.8	0.623	85.5	44.4	0.650	53.0	24.1
BC23122020_slice_7	0.792	0.108	0.061	0.792	108.2	60.7	0.628	85.7	44.5	0.654	53.2	23.9
BC23122020_slice_8	0.796	0.109	0.061	0.796	108.9	61.3	0.630	87.0	45.0	0.658	53.0	23.8
BC23122020_slice_9	0.796	0.110	0.062	0.796	109.9	61.8	0.630	87.6	45.2	0.656	53.0	23.7
BC23122020_slice_10	0.785	0.112	0.063	0.785	111.7	63.1	0.620	90.7	46.8	0.653	54.8	24.5
BC23122020_slice_11	0.787	0.112	0.064	0.787	112.2	63.9	0.619	91.8	47.5	0.654	54.4	24.3
BC23122020_slice_12	0.789	0.112	0.064	0.789	112.0	63.9	0.620	93.1	47.9	0.657	53.4	23.8
BC23122020_slice_13	0.781	0.114	0.065	0.781	114.0	65.3	0.612	96.7	49.8	0.657	54.8	24.4
BC23122020_slice_14	0.789	0.115	0.065	0.789	115.2	65.0	0.618	98.4	49.7	0.666	54.5	24.0
BC23122020_slice_15	0.787	0.117	0.066	0.787	116.8	65.7	0.611	101.2	50.7	0.663	53.8	23.9
BC23122020_slice_16	0.782	0.119	0.067	0.782	119.0	67.2	0.608	103.2	51.9	0.665	54.1	24.0
BC23122020_slice_17	0.785	0.119	0.067	0.785	119.4	67.3	0.608	104.0	52.1	0.663	53.9	23.7
BC23122020_slice_18	0.791	0.120	0.067	0.791	120.2	67.3	0.614	105.4	52.5	0.663	53.9	23.4
BC23122020_slice_19	0.801	0.120	0.067	0.801	120.5	66.8	0.622	106.4	52.4	0.670	52.2	22.5
BC23122020_slice_20	0.805	0.120	0.067	0.805	119.6	66.5	0.623	106.1	52.5	0.672	51.3	22.1
BC23122020_slice_21	0.799	0.121	0.067	0.799	121.1	67.2	0.617	108.2	53.2	0.670	51.6	22.3
BC23122020_slice_22	0.796	0.122	0.068	0.796	122.3	68.0	0.614	109.3	53.9	0.672	51.8	22.4
BC23122020_slice_23	0.792	0.123	0.069	0.792	123.1	68.9	0.611	109.9	54.5	0.675	52.1	22.6
BC23122020_slice_24	0.784	0.123	0.070	0.784	123.3	70.2	0.601	109.8	55.3	0.673	53.1	23.2
BC23122020_slice_25	0.778	0.124	0.071	0.778	124.4	70.9	0.597	110.8	56.1	0.672	54.0	23.6
BC23122020_slice_26	0.781	0.124	0.070	0.781	124.2	70.4	0.597	111.4	56.2	0.668	53.7	23.5
BC23122020_slice_27	0.784	0.126	0.070	0.784	126.1	70.5	0.598	113.2	56.4	0.669	52.1	22.7
BC23122020_slice_28	0.786	0.128	0.071	0.786	128.1	70.8	0.598	115.7	56.9	0.669	51.7	22.5
BC23122020_slice_29	0.781	0.133	0.073	0.781	133.3	72.7	0.595	119.7	58.3	0.669	52.5	22.7
BC23122020_slice_30	0.774	0.137	0.074	0.774	136.7	74.4	0.591	125.0	60.2	0.666	53.9	23.4
BC23122020_slice_31	0.762	0.144	0.078	0.762	144.1	77.7	0.579	132.4	63.0	0.661	57.0	24.8
BC23122020_slice_32	0.752	0.147	0.080	0.752	147.4	79.6	0.573	135.1	64.5	0.660	59.7	26.0
BC23122020_slice_33	0.744	0.149	0.081	0.744	149.3	81.4	0.566	137.3	66.3	0.659	61.4	26.9
BC23122020_slice_34	0.752	0.150	0.081	0.752	149.6	80.5	0.572	137.8	65.7	0.660	60.2	26.3
BC23122020_slice_35	0.757	0.152	0.081	0.757	152.0	81.0	0.577	141.0	66.6	0.664	58.9	25.8
BC23122020_slice_36	0.753	0.157	0.083	0.753	157.1	82.8	0.573	146.3	68.4	0.655	59.9	26.5
BC23122020_slice_37	0.741	0.159	0.085	0.741	159.1	84.6	0.561	147.9	70.0	0.652	61.5	27.2
BC23122020_slice_38	0.728	0.163	0.088	0.728	163.2	87.5	0.552	151.6	72.4	0.647	63.2	28.2
BC23122020_slice_39	0.726	0.162	0.088	0.726	162.3	88.0	0.552	150.2	72.4	0.645	63.4	28.3
BC23122020_slice_40	0.727	0.160	0.087	0.727	159.8	87.1	0.555	147.9	71.7	0.648	62.0	27.7
BC23122020_slice_41	0.725	0.163	0.089	0.725	163.0	88.5	0.554	151.6	73.1	0.648	63.4	28.3
BC23122020_slice_42	0.724	0.164	0.089	0.724	164.2	88.9	0.551	153.1	73.7	0.650	64.2	28.6
BC23122020_slice_43	0.726	0.165	0.089	0.726	165.1	88.9	0.551	154.5	74.2	0.648	64.1	28.7
BC23122020_slice_44	0.732	0.164	0.087	0.732	163.8	87.3	0.555	153.5	73.0	0.650	62.9	28.1
BC23122020_slice_45	0.731	0.161	0.087	0.731	160.9	86.8	0.556	150.8	72.5	0.647	63.1	28.3
BC23122020_slice_46	0.734	0.160	0.086	0.734	159.8	86.3	0.558	149.4	71.8	0.648	62.4	28.1
BC23122020_slice_47	0.728	0.164	0.089	0.728	163.8	88.8	0.554	153.3	73.9	0.645	62.5	28.3
BC23122020_slice_48	0.724	0.165	0.090	0.724	165.3	89.6	0.554	155.1	74.7	0.645	63.9	28.9
BC23122020_slice_49	0.718	0.171	0.092	0.718	170.9	91.6	0.551	161.1	76.8	0.642	66.3	30.1
BC23122020_slice_50	0.714	0.173	0.092	0.714	173.1	92.4	0.551	163.7	77.8	0.640	67.2	30.7
BC23122020_slice_51	0.731	0.170	0.090	0.731	170.3	90.0	0.563	161.1	76.0	0.647	65.6	29.4
BC23122020_slice_52	0.725	0.172	0.091	0.725	171.7	90.6	0.559	162.4	76.5	0.645	66.1	29.7
BC23122020_slice_53	0.734	0.166	0.088	0.734	165.9	88.2	0.567	156.6	74.4	0.646	64.6	29.1
BC23122020_slice_54	0.741	0.161	0.086	0.741	161.1	86.3	0.569	151.7	72.3	0.646	62.3	27.9
BC23122020_slice_55	0.743	0.161	0.086	0.743	160.6	85.7	0.569	151.3	71.7	0.644	61.5	27.6
BC23122020_slice_56	0.734	0.164	0.088	0.734	163.8	87.7	0.561	154.3	73.4	0.643	63.5	28.5
BC23122020_slice_57	0.733	0.164	0.088	0.733	163.5	87.6	0.562	154.1	73.4	0.644	63.8	28.6
BC23122020_slice_58	0.731	0.164	0.088	0.731	163.9	88.1	0.556	154.1	73.8	0.657	62.3	27.5
BC23122020_slice_59	0.735	0.161	0.086	0.735	161.4	86.3	0.561	151.3	71.8	0.662	63.4	27.9
BC23122020_slice_60	0.739	0.161	0.085	0.739	161.3	85.4	0.563	151.6	71.2	0.666	62.2	27.2
BC23122020_slice_61	0.735	0.162	0.086	0.735	162.4	86.5	0.558	152.7	72.1	0.672	61.8	26.9
BC23122020_slice_62	0.734	0.164	0.087	0.734	164.1	87.3	0.557	154.1	72.7	0.673	60.4	26.0
BC23122020_slice_63	0.739	0.163	0.086	0.739	162.8	86.4	0.561	153.1	72.2	0.678	58.5	25.1
BC23122020_slice_64	0.741	0.164	0.086	0.741	164.5	86.4	0.562	154.9	72.3	0.682	57.0	24.3
BC23122020_slice_65	0.738	0.171	0.088	0.738	170.8	88.5	0.562	161.8	74.7	0.683	57.1	24.3
BC23122020_slice_66	0.744	0.178	0.089	0.744	178.2	89.4	0.567	169.7	75.9	0.681	58.1	24.5
BC23122020_slice_67	0.746	0.187	0.091	0.746	186.6	91.1	0.570	178.6	77.9	0.680	60.3	25.0
BC23122020_slice_68	0.740	0.188	0.092	0.740	187.9	91.9	0.568	179.7	78.6	0.680	63.2	26.1
BC23122020_slice_69	0.736	0.187	0.092	0.736	187.1	91.6	0.564	178.9	78.3	0.677	63.7	26.3
BC23122020_slice_70	0.746	0.184	0.090	0.746	184.1	89.6	0.570	175.9	76.4	0.680	62.6	25.7
BC23122020_slice_71	0.741	0.187	0.091	0.741	186.8	91.4	0.565	178.1	77.8	0.678	62.9	25.8
BC23122020_slice_72	0.730	0.195	0.095	0.730	194.6	95.1	0.558	186.1	81.5	0.669	64.1	26.9
BC23122020_slice_73	0.730	0.199	0.097	0.730	198.9	96.7	0.557	190.1	82.7	0.656	64.1	27.4
BC23122020_slice_74	0.736	0.201	0.096	0.736	201.0	96.1	0.561	192.5	82.3	0.644	64.4	27.6
BC23122020_slice_75	0.739	0.203	0.096	0.739	203.1	96.2	0.564	194.9	82.7	0.638	64.6	28.0
BC23122020_slice_76	0.740	0.204	0.096	0.740	203.5	95.9	0.561	195.6	82.7	0.627	65.5	28.6
BC23122020_slice_77	0.743	0.204	0.095	0.743	203.7	95.1	0.562	196.2	82.3	0.618	66.0	29.0
BC23122020_slice_78	0.736	0.206	0.096	0.736	205.9	95.9	0.553	199.1	83.4	0.608	67.4	30.0
BC23122020_slice_79	0.741	0.206	0.095	0.741	206.2	95.3	0.557	199.6	83.1	0.604	67.2	30.1
BC23122020_slice_80	0.745	0.206	0.095	0.745	205.7	94.5	0.561	199.1	82.5	0.599	67.9	30.5
BC23122020_slice_81	0.744	0.204	0.094	0.744	204.2	93.7	0.560	197.7	81.9	0.595	68.8	31.2
BC23122020_slice_82	0.744	0.202	0.093	0.744	201.6	92.7	0.560	194.8	80.5	0.586	69.0	31.7
BC23122020_slice_83	0.737	0.201	0.093	0.737	201.0	93.1	0.554	194.1	80.7	0.580	69.9	32.7
BC23122020_slice_84	0.734	0.199	0.092	0.734	198.5	92.1	0.555	191.3	79.5	0.576	69.7	33.0
BC23122020_slice_85	0.734	0.196	0.091	0.734	195.9	90.7	0.555	188.5	78.0	0.574	68.6	32.8
BC23122020_slice_86	0.733	0.193	0.089	0.733	193.3	89.3	0.554	184.7	76.3	0.574	67.4	32.4
BC23122020_slice_87	0.736	0.188	0.087	0.736	187.5	87.2	0.555	179.0	74.2	0.574	66.2	32.1
BC23122020_slice_88	0.736	0.184	0.086	0.736	183.9	85.6	0.555	175.7	72.9	0.572	65.6	32.0
BC23122020_slice_89	0.733	0.179	0.084	0.733	179.1	84.1	0.550	171.0	71.7	0.566	65.3	32.2
BC23122020_slice_90	0.738	0.174	0.082	0.738	174.0	82.2	0.554	165.9	69.8	0.566	64.7	32.0
BC23122020_slice_91	0.745	0.168	0.080	0.745	168.0	79.8	0.559	160.4	67.8	0.566	63.7	31.6
BC23122020_slice_92	0.751	0.164	0.078	0.751	163.6	77.7	0.563	156.0	65.8	0.566	62.5	31.0
BC23122020_slice_93	0.744	0.161	0.078	0.744	161.5	77.6	0.559	153.1	65.2	0.564	63.6	31.6
BC23122020_slice_94	0.739	0.158	0.077	0.739	158.0	76.8	0.558	148.9	64.1	0.567	64.1	31.9
BC23122020_slice_95	0.730	0.156	0.077	0.730	155.9	76.8	0.554	146.4	64.0	0.565	66.1	32.9
BC23122020_slice_96	0.726	0.154	0.076	0.726	153.9	76.3	0.552	144.3	63.3	0.565	66.0	33.0
BC23122020_slice_97	0.724	0.151	0.075	0.724	150.8	75.2	0.550	141.2	62.3	0.566	64.7	32.7
BC23122020_slice_98	0.732	0.147	0.074	0.732	147.2	73.6	0.555	137.5	60.8	0.568	63.4	32.1
BC23122020_slice_99	0.738	0.143	0.072	0.738	143.0	71.8	0.558	134.6	59.5	0.568	62.0	31.5
BC23122020_slice_100	0.745	0.141	0.071	0.745	141.0	70.6	0.563	132.0	58.3	0.572	61.2	30.9
BC23122020_slice_101	0.746	0.140	0.070	0.746	140.1	70.3	0.565	129.5	57.5	0.575	60.8	30.6
BC23122020_slice_102	0.750	0.137	0.069	0.750	137.2	69.1	0.572	125.0	55.8	0.581	60.0	30.1
BC23122020_slice_103	0.750	0.134	0.068	0.750	133.7	67.7	0.573	120.8	54.3	0.585	60.0	30.0
BC23122020_slice_104	0.756	0.131	0.066	0.756	131.2	66.3	0.578	117.4	52.8	0.588	59.1	29.4
BC23122020_slice_105	0.763	0.128	0.065	0.763	127.8	64.8	0.584	114.5	51.4	0.588	57.8	28.7
BC23122020_slice_106	0.771	0.123	0.063	0.771	123.0	62.9	0.592	112.1	50.1	0.592	56.4	27.9
