GAN Evaluation Report - Patient PP08072020

Native→Venous Translation Metrics (Generated Venous vs Real Venous)

Targeted Slice 70 - Network-Normalized Analysis (Generated vs Real Venous)

0.795

SSIM Score

0.120

RMSE

0.067

MAE

Average Network-Normalized Metrics Across All Slices (112 slices) - Generated vs Real Venous

0.801

SSIM Score (Avg)

0.121

RMSE (Avg)

0.065

MAE (Avg)

Targeted Slice 70 - HU-Space Analysis (Generated vs Real Venous)

0.795

HU SSIM

119.9

HU RMSE

66.7

HU MAE

Average HU-Space Metrics Across All Slices (112 slices) - Generated vs Real Venous

0.801

HU SSIM (Avg)

121.2

HU RMSE (Avg)

65.0

HU MAE (Avg)

Targeted Slice 70 - Lung Window Analysis (Generated vs Real Venous)

0.609

Lung SSIM

106.8

Lung RMSE

53.6

Lung MAE

Average Lung Window Metrics Across All Slices (112 slices) - Generated vs Real Venous

0.626

Lung SSIM (Avg)

107.5

Lung RMSE (Avg)

51.7

Lung MAE (Avg)

Targeted Slice 70 - Mediastinum Window Analysis (Generated vs Real Venous)

0.778

Mediastinum SSIM

42.9

Mediastinum RMSE

15.0

Mediastinum MAE

Average Mediastinum Window Metrics Across All Slices (112 slices) - Generated vs Real Venous

0.723

Mediastinum SSIM (Avg)

45.5

Mediastinum RMSE (Avg)

18.0

Mediastinum MAE (Avg)

Detailed Per-Slice Metrics

Slice ID	SSIM	RMSE	MAE	HU SSIM	HU RMSE	HU MAE	Lung SSIM	Lung RMSE	Lung MAE	Mediastinum SSIM	Mediastinum RMSE	Mediastinum MAE
PP08072020_slice_0	0.809	0.108	0.058	0.809	107.7	58.3	0.657	86.1	41.4	0.661	47.8	21.1
PP08072020_slice_1	0.789	0.115	0.062	0.789	115.4	61.9	0.639	95.1	44.7	0.650	51.2	22.7
PP08072020_slice_2	0.776	0.114	0.062	0.776	114.1	62.4	0.625	92.1	44.9	0.641	56.5	24.8
PP08072020_slice_3	0.762	0.117	0.064	0.762	117.3	63.6	0.616	96.1	46.6	0.641	58.9	25.7
PP08072020_slice_4	0.761	0.127	0.067	0.761	127.0	66.7	0.617	104.4	49.0	0.643	60.0	25.7
PP08072020_slice_5	0.777	0.122	0.065	0.777	121.8	65.1	0.630	101.2	47.7	0.651	52.5	23.0
PP08072020_slice_6	0.790	0.112	0.061	0.790	111.8	60.9	0.640	89.0	43.7	0.658	49.3	21.4
PP08072020_slice_7	0.804	0.110	0.059	0.804	110.5	59.1	0.655	86.2	41.7	0.674	46.3	20.0
PP08072020_slice_8	0.808	0.110	0.058	0.808	110.2	58.4	0.656	85.0	41.5	0.680	45.6	19.5
PP08072020_slice_9	0.807	0.106	0.058	0.807	106.1	57.7	0.656	83.3	41.3	0.687	44.9	19.1
PP08072020_slice_10	0.810	0.103	0.057	0.810	102.7	57.3	0.659	82.5	41.2	0.697	44.4	18.7
PP08072020_slice_11	0.810	0.103	0.058	0.810	103.1	57.5	0.657	83.8	41.8	0.700	44.6	18.7
PP08072020_slice_12	0.810	0.105	0.058	0.810	104.9	58.4	0.652	87.1	43.2	0.699	44.8	18.5
PP08072020_slice_13	0.816	0.107	0.059	0.816	106.7	58.7	0.655	89.9	44.0	0.702	43.8	17.8
PP08072020_slice_14	0.829	0.107	0.058	0.829	107.2	58.2	0.666	89.7	43.5	0.718	41.5	16.6
PP08072020_slice_15	0.826	0.107	0.058	0.826	107.0	58.5	0.656	90.6	44.4	0.716	43.0	17.1
PP08072020_slice_16	0.828	0.107	0.059	0.828	106.8	58.9	0.656	90.3	44.9	0.719	42.7	17.0
PP08072020_slice_17	0.824	0.107	0.059	0.824	106.7	59.3	0.650	90.7	45.4	0.725	42.2	16.9
PP08072020_slice_18	0.820	0.108	0.060	0.820	108.5	59.8	0.647	92.3	45.7	0.729	42.8	17.0
PP08072020_slice_19	0.813	0.112	0.061	0.813	112.4	61.3	0.639	95.6	46.8	0.723	44.0	17.3
PP08072020_slice_20	0.814	0.113	0.061	0.814	113.0	61.4	0.640	96.8	47.2	0.725	44.0	17.0
PP08072020_slice_21	0.822	0.112	0.060	0.822	111.7	60.4	0.644	96.9	46.8	0.734	41.7	16.1
PP08072020_slice_22	0.823	0.109	0.060	0.823	109.4	59.7	0.643	95.3	46.7	0.733	40.6	16.0
PP08072020_slice_23	0.826	0.108	0.059	0.826	107.8	59.2	0.647	93.5	46.5	0.735	40.9	16.0
PP08072020_slice_24	0.827	0.107	0.059	0.827	107.2	59.5	0.647	92.7	46.7	0.740	41.0	15.9
PP08072020_slice_25	0.824	0.109	0.061	0.824	108.6	60.8	0.645	93.4	47.4	0.742	42.0	16.1
PP08072020_slice_26	0.819	0.112	0.062	0.819	112.3	62.0	0.644	96.0	48.0	0.740	43.5	16.5
PP08072020_slice_27	0.814	0.115	0.063	0.814	114.7	63.2	0.641	97.4	48.6	0.736	44.8	16.9
PP08072020_slice_28	0.812	0.115	0.063	0.812	114.7	63.3	0.640	95.8	48.1	0.738	45.0	17.0
PP08072020_slice_29	0.811	0.112	0.063	0.811	112.3	62.7	0.635	93.4	47.8	0.739	45.7	17.3
PP08072020_slice_30	0.812	0.109	0.062	0.812	108.9	62.0	0.634	91.0	47.5	0.742	45.3	17.1
PP08072020_slice_31	0.813	0.107	0.062	0.813	107.1	61.8	0.632	90.4	47.7	0.747	44.4	16.9
PP08072020_slice_32	0.813	0.108	0.062	0.813	108.2	62.2	0.629	92.4	48.6	0.747	43.8	16.7
PP08072020_slice_33	0.802	0.113	0.065	0.802	112.7	64.5	0.619	97.1	50.8	0.738	46.8	17.8
PP08072020_slice_34	0.798	0.118	0.066	0.798	117.6	66.4	0.617	101.4	51.8	0.734	46.4	17.7
PP08072020_slice_35	0.803	0.118	0.066	0.803	117.9	65.8	0.621	102.2	51.2	0.741	44.8	16.9
PP08072020_slice_36	0.802	0.117	0.065	0.802	117.1	65.2	0.622	101.2	50.6	0.742	43.9	16.6
PP08072020_slice_37	0.804	0.119	0.066	0.804	119.1	65.7	0.624	103.6	51.3	0.739	43.7	16.5
PP08072020_slice_38	0.807	0.119	0.066	0.807	118.8	65.5	0.627	105.1	51.8	0.740	43.5	16.5
PP08072020_slice_39	0.808	0.116	0.065	0.808	116.2	64.8	0.628	102.5	51.3	0.739	43.2	16.4
PP08072020_slice_40	0.804	0.116	0.065	0.804	115.9	64.7	0.623	101.7	51.2	0.738	43.4	16.5
PP08072020_slice_41	0.807	0.115	0.064	0.807	115.0	64.2	0.625	99.6	50.4	0.742	43.1	16.3
PP08072020_slice_42	0.806	0.113	0.064	0.806	113.5	63.8	0.623	97.2	49.8	0.742	44.5	16.9
PP08072020_slice_43	0.801	0.114	0.065	0.801	114.1	64.8	0.620	96.4	50.1	0.744	45.9	17.4
PP08072020_slice_44	0.795	0.115	0.065	0.795	114.6	65.3	0.615	97.1	50.5	0.742	46.2	17.5
PP08072020_slice_45	0.788	0.117	0.066	0.788	117.1	66.5	0.610	98.9	51.3	0.740	46.8	17.8
PP08072020_slice_46	0.783	0.121	0.068	0.783	120.8	68.3	0.602	103.7	53.3	0.732	48.2	18.5
PP08072020_slice_47	0.776	0.125	0.070	0.776	124.9	70.1	0.596	109.9	55.7	0.727	49.3	18.9
PP08072020_slice_48	0.778	0.126	0.070	0.778	125.6	70.3	0.598	112.5	56.4	0.729	46.8	18.1
PP08072020_slice_49	0.781	0.125	0.070	0.781	125.1	69.8	0.599	113.3	56.6	0.733	46.2	17.8
PP08072020_slice_50	0.782	0.127	0.070	0.782	127.3	70.5	0.598	116.4	57.7	0.733	46.6	18.0
PP08072020_slice_51	0.787	0.134	0.073	0.787	133.7	73.3	0.601	123.6	60.7	0.741	43.6	16.6
PP08072020_slice_52	0.790	0.127	0.071	0.790	126.6	70.7	0.606	115.8	58.1	0.750	42.9	16.2
PP08072020_slice_53	0.785	0.125	0.070	0.785	125.2	69.8	0.607	112.5	56.8	0.745	44.9	17.0
PP08072020_slice_54	0.778	0.127	0.071	0.778	127.3	71.1	0.602	113.4	57.7	0.744	45.8	17.2
PP08072020_slice_55	0.775	0.126	0.071	0.775	126.1	70.6	0.598	112.0	57.4	0.740	47.0	18.0
PP08072020_slice_56	0.777	0.123	0.069	0.777	123.5	69.5	0.599	108.4	55.9	0.740	47.7	18.2
PP08072020_slice_57	0.776	0.123	0.069	0.776	123.1	69.4	0.598	107.8	55.6	0.742	47.6	18.2
PP08072020_slice_58	0.773	0.123	0.070	0.773	122.7	69.8	0.589	107.9	56.1	0.739	48.4	18.5
PP08072020_slice_59	0.773	0.124	0.070	0.773	123.7	69.9	0.586	109.9	56.5	0.737	48.6	18.6
PP08072020_slice_60	0.766	0.128	0.072	0.766	127.7	72.0	0.579	114.2	58.4	0.738	49.4	18.8
PP08072020_slice_61	0.768	0.132	0.073	0.768	131.9	72.8	0.580	118.9	59.4	0.737	49.0	18.6
PP08072020_slice_62	0.773	0.132	0.072	0.773	131.5	71.8	0.586	118.2	58.2	0.741	47.7	18.0
PP08072020_slice_63	0.782	0.128	0.070	0.782	128.4	69.5	0.597	115.2	56.2	0.749	45.7	17.0
PP08072020_slice_64	0.791	0.123	0.067	0.791	122.8	67.4	0.604	110.7	54.6	0.761	44.2	16.4
PP08072020_slice_65	0.801	0.117	0.065	0.801	117.0	65.2	0.613	105.6	52.8	0.770	41.8	15.3
PP08072020_slice_66	0.807	0.114	0.064	0.807	114.0	64.0	0.619	103.1	51.8	0.778	39.9	14.5
PP08072020_slice_67	0.804	0.115	0.064	0.804	114.7	64.2	0.616	103.5	51.9	0.780	40.3	14.5
PP08072020_slice_68	0.797	0.117	0.066	0.797	117.1	65.6	0.609	105.6	53.1	0.778	42.0	15.0
PP08072020_slice_69	0.794	0.120	0.067	0.794	120.0	66.7	0.607	107.7	53.8	0.775	42.4	15.0
PP08072020_slice_70	0.795	0.120	0.067	0.795	119.9	66.7	0.609	106.8	53.6	0.778	42.9	15.0
PP08072020_slice_71	0.794	0.121	0.067	0.794	120.9	66.7	0.609	107.8	53.6	0.776	43.1	14.9
PP08072020_slice_72	0.792	0.122	0.067	0.792	121.9	67.4	0.607	108.3	54.0	0.777	43.0	15.0
PP08072020_slice_73	0.791	0.123	0.068	0.791	123.3	67.8	0.605	109.3	54.4	0.778	43.2	15.0
PP08072020_slice_74	0.793	0.122	0.067	0.793	121.8	67.5	0.607	107.2	53.9	0.780	43.0	14.8
PP08072020_slice_75	0.797	0.119	0.066	0.797	119.3	66.0	0.613	104.0	52.2	0.783	41.7	14.3
PP08072020_slice_76	0.803	0.116	0.064	0.803	115.6	64.5	0.618	101.2	51.0	0.788	40.1	13.7
PP08072020_slice_77	0.803	0.114	0.064	0.803	113.6	63.8	0.619	100.3	50.8	0.790	39.4	13.6
PP08072020_slice_78	0.806	0.109	0.062	0.806	109.3	62.3	0.623	96.8	49.7	0.795	38.4	13.3
PP08072020_slice_79	0.814	0.105	0.060	0.814	104.8	60.3	0.629	93.2	48.1	0.801	36.2	12.4
PP08072020_slice_80	0.819	0.103	0.059	0.819	102.9	59.2	0.632	91.8	47.4	0.802	35.4	12.2
PP08072020_slice_81	0.818	0.111	0.062	0.818	110.6	62.2	0.631	100.3	50.3	0.802	35.5	12.3
PP08072020_slice_82	0.807	0.141	0.072	0.807	141.1	71.8	0.625	132.8	59.8	0.785	38.3	13.5
PP08072020_slice_83	0.794	0.150	0.076	0.794	149.8	76.0	0.619	142.0	64.1	0.766	44.4	16.2
PP08072020_slice_84	0.791	0.147	0.074	0.791	147.3	73.8	0.619	139.0	62.0	0.754	47.8	17.6
PP08072020_slice_85	0.794	0.149	0.074	0.794	148.9	73.8	0.621	140.6	61.9	0.742	48.4	18.1
PP08072020_slice_86	0.789	0.155	0.076	0.789	155.2	76.3	0.616	147.0	64.3	0.730	49.5	18.9
PP08072020_slice_87	0.783	0.161	0.078	0.783	161.3	78.4	0.613	153.0	66.3	0.719	51.0	19.8
PP08072020_slice_88	0.779	0.164	0.079	0.779	164.1	79.4	0.609	155.8	67.4	0.711	52.2	20.5
PP08072020_slice_89	0.781	0.164	0.079	0.781	164.3	79.3	0.610	155.8	67.3	0.704	51.9	20.5
PP08072020_slice_90	0.791	0.160	0.077	0.791	160.2	76.9	0.617	152.5	65.4	0.703	50.1	20.1
PP08072020_slice_91	0.798	0.157	0.075	0.798	157.0	74.7	0.623	149.8	63.7	0.703	49.1	19.9
PP08072020_slice_92	0.800	0.158	0.074	0.800	157.8	74.3	0.626	151.1	63.6	0.703	48.9	20.0
PP08072020_slice_93	0.793	0.160	0.075	0.793	159.9	75.2	0.621	153.5	64.5	0.693	50.4	20.8
PP08072020_slice_94	0.799	0.157	0.074	0.799	157.5	73.8	0.628	151.1	63.0	0.690	50.3	20.8
PP08072020_slice_95	0.797	0.153	0.072	0.797	152.5	71.9	0.628	146.1	61.3	0.686	51.0	21.4
PP08072020_slice_96	0.796	0.148	0.071	0.796	148.1	70.7	0.627	141.2	60.0	0.673	51.8	22.0
PP08072020_slice_97	0.797	0.142	0.069	0.797	141.8	68.5	0.624	134.4	57.8	0.663	51.5	22.2
PP08072020_slice_98	0.797	0.135	0.066	0.797	134.7	65.8	0.624	126.5	55.1	0.657	51.4	22.5
PP08072020_slice_99	0.796	0.132	0.065	0.796	132.2	64.9	0.625	123.4	53.9	0.654	50.3	22.3
PP08072020_slice_100	0.797	0.132	0.065	0.797	131.6	64.7	0.625	121.9	53.2	0.649	49.5	22.0
PP08072020_slice_101	0.804	0.129	0.063	0.804	128.9	63.3	0.629	119.0	52.0	0.650	49.0	21.7
PP08072020_slice_102	0.811	0.124	0.061	0.811	124.3	61.2	0.632	115.0	50.3	0.650	47.6	21.2
PP08072020_slice_103	0.815	0.120	0.060	0.815	120.0	59.6	0.634	110.5	48.7	0.647	47.5	21.3
PP08072020_slice_104	0.821	0.112	0.057	0.821	112.2	57.1	0.641	102.4	46.2	0.651	46.2	20.9
PP08072020_slice_105	0.831	0.104	0.054	0.831	103.6	53.9	0.653	93.6	43.1	0.662	44.0	19.8
PP08072020_slice_106	0.839	0.098	0.052	0.839	98.2	52.2	0.661	88.0	41.5	0.670	43.0	19.3
PP08072020_slice_107	0.843	0.097	0.052	0.843	97.5	51.6	0.666	87.3	41.0	0.675	42.5	19.1
PP08072020_slice_108	0.846	0.098	0.051	0.846	97.6	51.3	0.668	87.4	40.8	0.676	41.6	18.7
PP08072020_slice_109	0.844	0.102	0.052	0.844	101.5	52.1	0.666	91.6	41.6	0.676	41.6	18.7
PP08072020_slice_110	0.841	0.104	0.053	0.841	103.6	52.8	0.663	93.4	42.1	0.672	42.5	19.1
PP08072020_slice_111	0.839	0.103	0.053	0.839	103.1	53.0	0.660	92.6	42.1	0.670	42.3	19.1
