GAN Evaluation Report - Patient PP08072020

Native→Venous Translation Metrics (Generated Venous vs Real Venous)

Targeted Slice 70 - Network-Normalized Analysis (Generated vs Real Venous)

0.857

SSIM Score

0.111

RMSE

0.053

MAE

Average Network-Normalized Metrics Across All Slices (112 slices) - Generated vs Real Venous

0.858

SSIM Score (Avg)

0.113

RMSE (Avg)

0.052

MAE (Avg)

Targeted Slice 70 - HU-Space Analysis (Generated vs Real Venous)

0.857

HU SSIM

110.8

HU RMSE

52.9

HU MAE

Average HU-Space Metrics Across All Slices (112 slices) - Generated vs Real Venous

0.858

HU SSIM (Avg)

113.5

HU RMSE (Avg)

52.3

HU MAE (Avg)

Targeted Slice 70 - Lung Window Analysis (Generated vs Real Venous)

0.735

Lung SSIM

98.3

Lung RMSE

42.7

Lung MAE

Average Lung Window Metrics Across All Slices (112 slices) - Generated vs Real Venous

0.747

Lung SSIM (Avg)

100.1

Lung RMSE (Avg)

41.7

Lung MAE (Avg)

Targeted Slice 70 - Mediastinum Window Analysis (Generated vs Real Venous)

0.805

Mediastinum SSIM

38.0

Mediastinum RMSE

12.5

Mediastinum MAE

Average Mediastinum Window Metrics Across All Slices (112 slices) - Generated vs Real Venous

0.755

Mediastinum SSIM (Avg)

40.1

Mediastinum RMSE (Avg)

14.7

Mediastinum MAE (Avg)

Detailed Per-Slice Metrics

Slice ID	SSIM	RMSE	MAE	HU SSIM	HU RMSE	HU MAE	Lung SSIM	Lung RMSE	Lung MAE	Mediastinum SSIM	Mediastinum RMSE	Mediastinum MAE
PP08072020_slice_0	0.872	0.099	0.046	0.872	99.4	46.1	0.777	78.1	31.7	0.706	39.4	16.1
PP08072020_slice_1	0.857	0.108	0.049	0.857	108.0	49.4	0.763	88.5	34.8	0.692	43.6	17.8
PP08072020_slice_2	0.847	0.106	0.050	0.847	106.5	49.9	0.750	84.3	34.8	0.682	49.2	19.9
PP08072020_slice_3	0.842	0.109	0.051	0.842	108.7	50.5	0.747	87.4	36.0	0.682	50.5	20.2
PP08072020_slice_4	0.847	0.118	0.053	0.847	117.5	52.8	0.754	94.8	37.6	0.688	51.3	19.7
PP08072020_slice_5	0.845	0.114	0.053	0.845	113.9	52.5	0.754	93.2	37.7	0.691	45.1	18.3
PP08072020_slice_6	0.853	0.103	0.048	0.853	103.4	48.3	0.763	80.8	33.8	0.696	42.1	17.0
PP08072020_slice_7	0.859	0.103	0.047	0.859	102.9	47.0	0.770	78.9	32.3	0.708	40.5	16.3
PP08072020_slice_8	0.864	0.103	0.046	0.864	103.0	46.0	0.774	78.0	32.0	0.717	39.5	15.7
PP08072020_slice_9	0.872	0.099	0.045	0.872	98.5	45.0	0.782	75.9	31.3	0.728	37.9	14.9
PP08072020_slice_10	0.863	0.095	0.045	0.863	95.0	45.2	0.772	75.1	31.9	0.731	38.8	15.4
PP08072020_slice_11	0.870	0.095	0.045	0.870	95.2	44.9	0.779	76.3	32.0	0.738	38.6	14.9
PP08072020_slice_12	0.865	0.097	0.046	0.865	97.2	45.9	0.772	79.6	33.4	0.733	39.1	15.0
PP08072020_slice_13	0.875	0.098	0.045	0.875	98.3	45.5	0.782	81.5	33.4	0.741	38.0	14.0
PP08072020_slice_14	0.881	0.099	0.045	0.881	99.3	45.4	0.787	82.3	33.5	0.752	36.6	13.3
PP08072020_slice_15	0.881	0.099	0.045	0.881	98.7	45.4	0.784	82.5	33.9	0.751	37.5	13.5
PP08072020_slice_16	0.880	0.098	0.046	0.880	98.4	45.9	0.779	82.2	34.5	0.752	37.6	13.7
PP08072020_slice_17	0.880	0.097	0.046	0.880	97.5	45.7	0.779	81.5	34.4	0.757	36.9	13.4
PP08072020_slice_18	0.878	0.099	0.046	0.878	99.3	46.1	0.777	83.1	34.6	0.763	37.5	13.5
PP08072020_slice_19	0.872	0.102	0.047	0.872	102.5	47.4	0.770	85.9	35.6	0.761	38.6	13.7
PP08072020_slice_20	0.871	0.104	0.048	0.871	103.6	47.6	0.768	87.7	36.1	0.762	38.6	13.6
PP08072020_slice_21	0.876	0.103	0.047	0.876	102.8	47.1	0.770	88.2	36.1	0.771	36.9	13.0
PP08072020_slice_22	0.877	0.101	0.047	0.877	101.4	46.8	0.769	87.8	36.4	0.769	35.8	12.9
PP08072020_slice_23	0.880	0.099	0.046	0.880	99.5	46.1	0.775	85.6	36.0	0.774	36.1	12.9
PP08072020_slice_24	0.881	0.099	0.046	0.881	98.9	46.3	0.776	84.6	36.2	0.778	36.0	12.8
PP08072020_slice_25	0.878	0.100	0.048	0.878	100.1	47.6	0.774	84.8	36.9	0.781	36.9	12.9
PP08072020_slice_26	0.876	0.104	0.049	0.876	103.6	48.6	0.774	87.2	37.2	0.779	38.5	13.2
PP08072020_slice_27	0.873	0.106	0.049	0.873	105.8	49.4	0.773	88.5	37.6	0.773	39.9	13.7
PP08072020_slice_28	0.870	0.106	0.050	0.870	105.9	49.6	0.768	87.0	37.2	0.771	40.5	13.9
PP08072020_slice_29	0.869	0.103	0.049	0.869	103.0	49.0	0.763	84.3	36.9	0.769	41.0	14.2
PP08072020_slice_30	0.869	0.100	0.048	0.869	99.5	48.3	0.764	81.5	36.6	0.773	40.3	14.2
PP08072020_slice_31	0.870	0.098	0.048	0.870	97.5	48.0	0.759	80.7	36.8	0.774	39.5	14.2
PP08072020_slice_32	0.867	0.099	0.049	0.867	98.5	48.8	0.751	83.2	37.9	0.774	38.8	14.1
PP08072020_slice_33	0.861	0.103	0.051	0.861	103.0	50.9	0.744	87.4	39.7	0.770	41.7	14.8
PP08072020_slice_34	0.860	0.108	0.053	0.860	108.4	52.6	0.744	92.5	40.7	0.769	41.1	14.5
PP08072020_slice_35	0.862	0.109	0.052	0.862	109.4	52.2	0.747	94.0	40.3	0.775	40.1	13.8
PP08072020_slice_36	0.857	0.109	0.052	0.857	108.8	52.2	0.742	93.1	40.5	0.773	39.4	13.7
PP08072020_slice_37	0.857	0.111	0.053	0.857	111.0	53.0	0.743	95.9	41.5	0.772	39.3	13.7
PP08072020_slice_38	0.859	0.111	0.053	0.859	110.9	52.9	0.748	97.7	42.0	0.773	39.4	13.7
PP08072020_slice_39	0.862	0.108	0.052	0.862	108.4	52.2	0.748	95.3	41.6	0.771	38.9	13.5
PP08072020_slice_40	0.861	0.108	0.051	0.861	107.5	51.3	0.746	93.7	40.6	0.772	38.6	13.4
PP08072020_slice_41	0.865	0.106	0.050	0.865	105.9	50.1	0.752	90.5	39.3	0.779	37.9	13.1
PP08072020_slice_42	0.865	0.105	0.050	0.865	104.6	50.1	0.750	87.8	38.9	0.776	39.6	13.7
PP08072020_slice_43	0.862	0.105	0.051	0.862	105.0	50.9	0.747	87.1	39.1	0.775	41.2	14.4
PP08072020_slice_44	0.858	0.105	0.051	0.858	105.5	51.3	0.743	87.6	39.4	0.772	41.3	14.4
PP08072020_slice_45	0.849	0.107	0.053	0.849	107.5	52.6	0.733	89.6	40.5	0.768	41.8	14.8
PP08072020_slice_46	0.843	0.112	0.055	0.843	112.3	54.6	0.726	95.3	42.6	0.759	43.2	15.6
PP08072020_slice_47	0.835	0.116	0.057	0.835	116.5	56.8	0.715	101.8	45.4	0.753	44.3	16.0
PP08072020_slice_48	0.834	0.117	0.057	0.834	117.3	57.1	0.714	104.9	46.4	0.754	42.2	15.5
PP08072020_slice_49	0.837	0.117	0.057	0.837	116.9	56.8	0.714	105.8	46.7	0.757	42.0	15.3
PP08072020_slice_50	0.836	0.120	0.058	0.836	119.5	57.8	0.711	109.1	48.0	0.757	43.2	15.7
PP08072020_slice_51	0.843	0.128	0.060	0.843	127.7	60.3	0.721	118.3	50.6	0.768	39.6	14.1
PP08072020_slice_52	0.849	0.118	0.058	0.849	118.2	57.5	0.723	107.8	47.8	0.779	37.6	13.2
PP08072020_slice_53	0.844	0.116	0.057	0.844	116.2	56.6	0.722	103.8	46.5	0.774	39.4	13.9
PP08072020_slice_54	0.831	0.119	0.059	0.831	119.1	58.6	0.708	105.5	48.0	0.772	41.0	14.6
PP08072020_slice_55	0.833	0.118	0.058	0.833	117.9	58.0	0.711	103.9	47.4	0.769	41.6	15.1
PP08072020_slice_56	0.836	0.115	0.057	0.836	115.2	56.9	0.715	100.2	46.0	0.768	42.1	15.3
PP08072020_slice_57	0.832	0.114	0.057	0.832	114.4	56.8	0.713	99.1	45.7	0.771	42.9	15.7
PP08072020_slice_58	0.828	0.114	0.057	0.828	113.9	57.1	0.707	99.1	46.2	0.765	43.7	16.1
PP08072020_slice_59	0.829	0.115	0.057	0.829	114.7	57.0	0.705	101.3	46.5	0.763	43.9	16.2
PP08072020_slice_60	0.825	0.119	0.059	0.825	119.0	58.7	0.700	106.2	48.1	0.762	44.7	16.4
PP08072020_slice_61	0.827	0.123	0.059	0.827	123.2	59.3	0.701	110.7	48.8	0.761	44.1	16.1
PP08072020_slice_62	0.831	0.123	0.058	0.831	123.4	58.5	0.707	110.6	47.9	0.765	43.2	15.6
PP08072020_slice_63	0.840	0.121	0.057	0.840	120.6	56.8	0.718	108.0	46.4	0.773	41.2	14.7
PP08072020_slice_64	0.849	0.115	0.055	0.849	115.4	54.8	0.728	103.9	44.9	0.784	39.9	14.1
PP08072020_slice_65	0.862	0.109	0.052	0.862	108.6	52.1	0.743	97.9	42.6	0.796	36.9	12.9
PP08072020_slice_66	0.866	0.106	0.051	0.866	105.5	51.2	0.744	95.2	42.0	0.801	35.4	12.2
PP08072020_slice_67	0.866	0.107	0.051	0.866	106.6	51.2	0.743	96.0	41.8	0.804	35.1	12.0
PP08072020_slice_68	0.861	0.108	0.052	0.861	108.1	51.8	0.738	96.9	42.2	0.804	36.3	12.3
PP08072020_slice_69	0.859	0.110	0.052	0.859	110.0	52.4	0.736	98.3	42.5	0.803	37.0	12.4
PP08072020_slice_70	0.857	0.111	0.053	0.857	110.8	52.9	0.735	98.3	42.7	0.805	38.0	12.5
PP08072020_slice_71	0.855	0.112	0.053	0.855	112.2	53.5	0.733	99.3	43.1	0.804	38.5	12.6
PP08072020_slice_72	0.853	0.113	0.054	0.853	113.2	53.9	0.733	100.3	43.4	0.802	38.4	12.7
PP08072020_slice_73	0.854	0.114	0.054	0.854	114.3	54.0	0.732	101.3	43.6	0.805	38.4	12.6
PP08072020_slice_74	0.855	0.113	0.054	0.855	112.9	53.7	0.732	99.5	43.3	0.807	38.2	12.4
PP08072020_slice_75	0.858	0.111	0.052	0.858	110.6	52.1	0.736	96.2	41.5	0.810	36.9	11.7
PP08072020_slice_76	0.865	0.107	0.051	0.865	107.2	50.9	0.742	93.8	40.7	0.814	35.2	11.0
PP08072020_slice_77	0.867	0.105	0.050	0.867	104.6	50.1	0.745	92.4	40.4	0.818	33.8	10.7
PP08072020_slice_78	0.869	0.100	0.049	0.869	100.4	49.2	0.746	88.8	39.7	0.822	32.5	10.5
PP08072020_slice_79	0.879	0.095	0.047	0.879	95.4	46.7	0.755	84.7	37.7	0.830	29.7	9.4
PP08072020_slice_80	0.889	0.093	0.045	0.889	93.4	45.1	0.767	83.0	36.2	0.837	28.0	8.6
PP08072020_slice_81	0.887	0.103	0.049	0.887	103.1	48.9	0.763	94.0	40.2	0.838	28.4	8.7
PP08072020_slice_82	0.870	0.138	0.060	0.870	138.1	59.7	0.750	131.1	50.8	0.820	32.4	10.2
PP08072020_slice_83	0.849	0.145	0.064	0.849	144.6	63.6	0.732	137.7	54.4	0.794	39.9	13.4
PP08072020_slice_84	0.847	0.143	0.061	0.847	142.6	61.4	0.735	135.2	52.5	0.785	43.4	14.6
PP08072020_slice_85	0.844	0.144	0.061	0.844	144.5	61.5	0.735	137.1	52.5	0.769	44.6	15.5
PP08072020_slice_86	0.838	0.151	0.064	0.838	150.8	63.8	0.732	143.4	54.7	0.758	45.5	16.2
PP08072020_slice_87	0.829	0.157	0.066	0.829	157.1	66.2	0.727	149.5	56.9	0.746	47.3	17.3
PP08072020_slice_88	0.825	0.160	0.067	0.825	159.9	67.3	0.724	152.2	58.0	0.740	48.7	18.0
PP08072020_slice_89	0.827	0.160	0.067	0.827	159.9	66.9	0.726	152.1	57.7	0.734	48.2	17.7
PP08072020_slice_90	0.834	0.156	0.065	0.834	155.7	64.9	0.731	148.5	55.9	0.732	46.2	17.3
PP08072020_slice_91	0.846	0.153	0.063	0.846	152.9	62.7	0.742	146.4	54.2	0.736	44.7	16.6
PP08072020_slice_92	0.846	0.153	0.063	0.846	153.5	62.5	0.743	147.4	54.3	0.734	44.1	16.5
PP08072020_slice_93	0.844	0.155	0.063	0.844	154.5	62.8	0.741	148.6	54.5	0.727	44.9	16.9
PP08072020_slice_94	0.848	0.152	0.062	0.848	152.3	61.6	0.746	146.5	53.3	0.726	44.8	16.7
PP08072020_slice_95	0.847	0.147	0.060	0.847	147.3	59.8	0.745	141.5	51.7	0.722	45.3	17.0
PP08072020_slice_96	0.845	0.143	0.059	0.845	143.1	58.8	0.743	136.8	50.5	0.712	45.8	17.4
PP08072020_slice_97	0.846	0.136	0.057	0.846	136.1	56.5	0.741	129.1	48.2	0.702	45.3	17.6
PP08072020_slice_98	0.851	0.128	0.053	0.851	128.0	53.2	0.745	120.0	44.7	0.698	44.3	17.4
PP08072020_slice_99	0.853	0.126	0.053	0.853	125.9	52.6	0.745	117.5	43.8	0.693	42.6	17.0
PP08072020_slice_100	0.853	0.125	0.053	0.853	125.1	52.5	0.743	116.1	43.4	0.687	41.6	16.7
PP08072020_slice_101	0.853	0.123	0.052	0.853	123.3	52.2	0.740	113.9	43.2	0.684	42.2	17.0
PP08072020_slice_102	0.854	0.118	0.051	0.854	118.0	50.6	0.741	109.1	41.9	0.684	41.8	17.3
PP08072020_slice_103	0.858	0.114	0.049	0.858	113.8	49.1	0.743	104.5	40.4	0.682	41.4	17.3
PP08072020_slice_104	0.865	0.105	0.046	0.865	105.2	46.4	0.750	95.5	37.7	0.685	39.8	16.8
PP08072020_slice_105	0.875	0.096	0.043	0.875	95.8	42.9	0.762	86.0	34.4	0.696	37.3	15.7
PP08072020_slice_106	0.882	0.091	0.042	0.882	90.6	41.5	0.771	80.4	33.0	0.705	36.0	15.4
PP08072020_slice_107	0.886	0.090	0.041	0.886	90.4	41.0	0.775	80.4	32.7	0.708	35.3	15.1
PP08072020_slice_108	0.886	0.091	0.041	0.886	91.4	41.1	0.775	81.5	32.8	0.710	34.9	15.0
PP08072020_slice_109	0.880	0.096	0.042	0.880	95.9	42.5	0.770	86.3	34.2	0.709	35.8	15.5
PP08072020_slice_110	0.876	0.099	0.044	0.876	98.7	43.6	0.766	88.9	35.1	0.706	37.1	16.1
PP08072020_slice_111	0.876	0.097	0.043	0.876	97.4	43.2	0.765	87.1	34.6	0.706	36.5	15.9
