GAN Evaluation Report - Patient SE04022021

Native→Venous Translation Metrics (Generated Venous vs Real Venous)

Targeted Slice 70 - Network-Normalized Analysis (Generated vs Real Venous)

0.765

SSIM Score

0.179

RMSE

0.128

MAE

Average Network-Normalized Metrics Across All Slices (88 slices) - Generated vs Real Venous

0.789

SSIM Score (Avg)

0.180

RMSE (Avg)

0.130

MAE (Avg)

Targeted Slice 70 - HU-Space Analysis (Generated vs Real Venous)

0.774

HU SSIM

131.3

HU RMSE

72.6

HU MAE

Average HU-Space Metrics Across All Slices (88 slices) - Generated vs Real Venous

0.797

HU SSIM (Avg)

135.0

HU RMSE (Avg)

77.1

HU MAE (Avg)

Targeted Slice 70 - Lung Window Analysis (Generated vs Real Venous)

0.578

Lung SSIM

178.7

Lung RMSE

126.6

Lung MAE

Average Lung Window Metrics Across All Slices (88 slices) - Generated vs Real Venous

0.602

Lung SSIM (Avg)

178.9

Lung RMSE (Avg)

128.4

Lung MAE (Avg)

Targeted Slice 70 - Mediastinum Window Analysis (Generated vs Real Venous)

0.458

Mediastinum SSIM

57.5

Mediastinum RMSE

33.9

Mediastinum MAE

Average Mediastinum Window Metrics Across All Slices (88 slices) - Generated vs Real Venous

0.538

Mediastinum SSIM (Avg)

52.5

Mediastinum RMSE (Avg)

27.3

Mediastinum MAE (Avg)

Detailed Per-Slice Metrics

Slice ID	SSIM	RMSE	MAE	HU SSIM	HU RMSE	HU MAE	Lung SSIM	Lung RMSE	Lung MAE	Mediastinum SSIM	Mediastinum RMSE	Mediastinum MAE
SE04022021_slice_0	0.807	0.156	0.115	0.813	115.8	68.7	0.636	153.6	112.1	0.544	53.3	27.4
SE04022021_slice_1	0.816	0.154	0.113	0.822	115.3	67.6	0.640	152.2	110.5	0.547	51.3	26.4
SE04022021_slice_2	0.838	0.153	0.112	0.844	113.3	66.0	0.659	151.3	109.3	0.560	47.1	24.2
SE04022021_slice_3	0.843	0.154	0.112	0.849	112.9	65.5	0.663	152.3	109.8	0.562	46.1	23.6
SE04022021_slice_4	0.834	0.154	0.113	0.840	113.8	66.2	0.653	152.7	110.2	0.559	47.3	24.1
SE04022021_slice_5	0.831	0.153	0.112	0.838	114.3	66.6	0.648	151.8	109.9	0.562	47.7	24.4
SE04022021_slice_6	0.823	0.151	0.111	0.829	113.8	66.8	0.638	149.8	109.1	0.564	48.1	24.8
SE04022021_slice_7	0.820	0.152	0.112	0.826	114.1	67.1	0.635	150.5	109.8	0.568	48.6	24.5
SE04022021_slice_8	0.838	0.156	0.114	0.845	115.4	67.3	0.654	154.2	111.8	0.581	45.7	22.5
SE04022021_slice_9	0.836	0.159	0.116	0.842	118.2	68.7	0.654	156.8	113.5	0.587	46.5	22.2
SE04022021_slice_10	0.831	0.164	0.120	0.837	123.0	71.7	0.649	162.2	117.7	0.589	47.4	22.5
SE04022021_slice_11	0.835	0.160	0.118	0.841	121.2	70.7	0.650	158.6	115.1	0.595	46.2	22.0
SE04022021_slice_12	0.839	0.161	0.119	0.845	120.5	71.0	0.658	159.2	116.2	0.602	44.9	21.3
SE04022021_slice_13	0.840	0.160	0.118	0.847	119.1	70.0	0.660	158.2	115.4	0.608	44.3	20.8
SE04022021_slice_14	0.838	0.161	0.119	0.844	120.7	71.4	0.657	159.2	116.7	0.615	44.5	20.9
SE04022021_slice_15	0.835	0.161	0.119	0.841	121.5	71.8	0.652	159.3	116.7	0.612	44.7	21.0
SE04022021_slice_16	0.827	0.163	0.120	0.833	124.0	73.1	0.641	161.2	118.1	0.607	45.6	21.2
SE04022021_slice_17	0.822	0.161	0.118	0.829	123.5	72.4	0.632	159.5	116.6	0.604	45.7	21.2
SE04022021_slice_18	0.818	0.166	0.123	0.825	126.9	75.1	0.629	165.0	121.1	0.606	46.4	21.5
SE04022021_slice_19	0.814	0.167	0.124	0.821	128.6	75.9	0.623	166.0	121.6	0.602	46.6	21.7
SE04022021_slice_20	0.808	0.170	0.125	0.815	131.2	76.8	0.614	168.6	122.9	0.598	47.6	22.1
SE04022021_slice_21	0.804	0.170	0.126	0.811	130.9	77.4	0.611	169.0	124.0	0.596	47.7	22.3
SE04022021_slice_22	0.797	0.173	0.129	0.803	131.6	78.9	0.605	171.4	126.8	0.594	47.7	22.7
SE04022021_slice_23	0.792	0.177	0.133	0.798	134.8	81.6	0.602	175.0	130.3	0.594	48.3	23.3
SE04022021_slice_24	0.801	0.175	0.131	0.807	134.5	80.2	0.609	173.9	128.4	0.599	46.6	22.4
SE04022021_slice_25	0.800	0.172	0.127	0.807	132.5	78.7	0.607	170.4	125.5	0.601	47.2	22.6
SE04022021_slice_26	0.802	0.169	0.126	0.809	128.5	77.4	0.610	167.7	124.4	0.606	47.0	22.8
SE04022021_slice_27	0.796	0.169	0.127	0.803	128.7	78.4	0.602	167.8	125.3	0.599	48.3	23.6
SE04022021_slice_28	0.795	0.169	0.127	0.802	127.7	77.7	0.600	168.1	125.3	0.598	48.3	23.7
SE04022021_slice_29	0.797	0.171	0.128	0.804	129.4	78.5	0.603	169.6	126.3	0.595	48.1	23.5
SE04022021_slice_30	0.788	0.173	0.131	0.795	131.8	80.7	0.590	171.7	128.7	0.587	48.8	24.2
SE04022021_slice_31	0.789	0.173	0.129	0.796	132.6	79.8	0.590	171.5	127.4	0.585	48.2	23.8
SE04022021_slice_32	0.783	0.170	0.127	0.790	131.0	78.5	0.586	169.1	125.3	0.577	49.4	24.4
SE04022021_slice_33	0.786	0.170	0.127	0.793	130.1	77.6	0.592	169.4	125.1	0.585	49.0	24.1
SE04022021_slice_34	0.791	0.175	0.131	0.798	131.5	79.3	0.599	173.6	128.9	0.585	48.9	24.3
SE04022021_slice_35	0.790	0.174	0.130	0.798	130.7	78.6	0.596	173.3	128.4	0.580	48.7	24.2
SE04022021_slice_36	0.786	0.176	0.131	0.793	132.6	79.3	0.594	175.2	129.4	0.576	49.5	24.6
SE04022021_slice_37	0.779	0.178	0.132	0.787	135.4	80.5	0.584	176.7	130.2	0.572	50.3	25.2
SE04022021_slice_38	0.784	0.176	0.132	0.792	133.0	79.7	0.590	175.4	129.7	0.574	49.8	24.9
SE04022021_slice_39	0.786	0.177	0.132	0.794	133.4	80.0	0.589	176.1	130.3	0.571	50.2	25.0
SE04022021_slice_40	0.790	0.178	0.133	0.797	133.2	79.9	0.593	176.7	130.7	0.572	50.1	24.9
SE04022021_slice_41	0.791	0.178	0.132	0.798	134.3	80.3	0.594	176.8	130.7	0.575	49.1	24.5
SE04022021_slice_42	0.794	0.175	0.131	0.801	131.8	79.1	0.601	174.4	129.2	0.584	48.8	24.4
SE04022021_slice_43	0.797	0.173	0.129	0.804	129.2	77.9	0.605	171.7	127.5	0.587	48.9	24.4
SE04022021_slice_44	0.795	0.174	0.132	0.802	127.8	78.7	0.601	173.5	130.1	0.585	49.1	24.7
SE04022021_slice_45	0.787	0.181	0.139	0.794	131.7	83.1	0.598	179.9	136.7	0.582	49.9	25.5
SE04022021_slice_46	0.787	0.177	0.135	0.795	130.9	82.1	0.597	175.6	133.4	0.586	49.8	25.0
SE04022021_slice_47	0.782	0.191	0.143	0.789	149.6	89.4	0.593	189.7	140.6	0.578	50.5	25.5
SE04022021_slice_48	0.775	0.211	0.151	0.783	174.3	97.1	0.590	210.4	148.8	0.570	55.5	27.4
SE04022021_slice_49	0.766	0.213	0.149	0.773	181.6	98.3	0.581	212.7	146.8	0.561	60.3	29.6
SE04022021_slice_50	0.766	0.208	0.147	0.774	173.5	95.4	0.587	207.4	145.3	0.562	60.8	30.2
SE04022021_slice_51	0.773	0.203	0.144	0.781	166.3	92.0	0.593	202.2	142.5	0.558	59.1	29.6
SE04022021_slice_52	0.776	0.200	0.143	0.783	161.1	89.8	0.591	199.1	141.4	0.552	58.6	29.3
SE04022021_slice_53	0.778	0.197	0.141	0.785	157.4	87.9	0.592	196.0	139.5	0.551	57.8	29.0
SE04022021_slice_54	0.784	0.194	0.138	0.791	156.0	85.9	0.600	193.3	136.4	0.555	57.4	28.3
SE04022021_slice_55	0.778	0.199	0.143	0.785	158.1	87.8	0.594	198.8	141.2	0.551	57.6	28.4
SE04022021_slice_56	0.772	0.199	0.142	0.780	158.6	87.9	0.588	198.7	140.9	0.544	58.1	28.6
SE04022021_slice_57	0.765	0.205	0.145	0.773	165.9	90.9	0.582	204.2	143.6	0.540	58.3	29.2
SE04022021_slice_58	0.762	0.207	0.147	0.770	167.8	92.1	0.580	206.6	145.4	0.532	58.5	29.9
SE04022021_slice_59	0.754	0.205	0.145	0.762	164.8	90.7	0.568	204.1	144.0	0.517	59.6	31.0
SE04022021_slice_60	0.756	0.201	0.143	0.763	159.8	88.0	0.569	200.3	141.5	0.512	59.2	31.2
SE04022021_slice_61	0.761	0.199	0.142	0.769	155.7	86.0	0.578	198.7	140.8	0.509	58.0	30.8
SE04022021_slice_62	0.771	0.197	0.140	0.779	152.2	83.5	0.586	196.8	138.8	0.502	56.8	30.1
SE04022021_slice_63	0.781	0.194	0.136	0.788	149.2	80.5	0.591	193.4	135.1	0.494	55.8	29.5
SE04022021_slice_64	0.788	0.193	0.134	0.796	146.4	77.8	0.597	192.0	133.1	0.494	54.6	29.0
SE04022021_slice_65	0.794	0.192	0.134	0.802	144.7	76.5	0.602	191.8	132.6	0.490	54.3	29.0
SE04022021_slice_66	0.796	0.189	0.131	0.804	141.1	74.5	0.606	188.5	130.2	0.490	54.2	29.4
SE04022021_slice_67	0.792	0.185	0.129	0.800	138.2	73.7	0.600	184.1	127.9	0.483	54.9	30.7
SE04022021_slice_68	0.791	0.187	0.131	0.799	138.1	74.1	0.601	186.0	129.5	0.474	54.9	31.2
SE04022021_slice_69	0.772	0.178	0.126	0.780	133.9	72.8	0.580	177.6	124.6	0.463	56.8	33.3
SE04022021_slice_70	0.765	0.179	0.128	0.774	131.3	72.6	0.578	178.7	126.6	0.458	57.5	33.9
SE04022021_slice_71	0.768	0.187	0.133	0.776	131.8	73.3	0.585	186.3	132.0	0.458	57.3	33.7
SE04022021_slice_72	0.769	0.191	0.135	0.777	131.1	73.1	0.585	190.3	134.4	0.449	57.1	33.6
SE04022021_slice_73	0.767	0.196	0.138	0.776	133.0	74.0	0.585	195.2	137.1	0.442	57.5	33.7
SE04022021_slice_74	0.768	0.195	0.138	0.776	132.4	73.2	0.583	194.9	136.3	0.438	57.7	33.6
SE04022021_slice_75	0.773	0.196	0.137	0.781	132.0	72.0	0.587	195.4	135.5	0.436	56.7	33.0
SE04022021_slice_76	0.771	0.194	0.135	0.780	130.2	70.7	0.585	193.2	133.7	0.434	56.5	32.8
SE04022021_slice_77	0.763	0.190	0.132	0.771	130.5	69.8	0.578	189.0	130.3	0.430	57.5	33.5
SE04022021_slice_78	0.767	0.197	0.136	0.776	135.5	71.8	0.585	196.7	134.2	0.430	56.4	32.8
SE04022021_slice_79	0.772	0.190	0.130	0.781	134.0	69.3	0.586	189.6	128.6	0.427	57.2	33.0
SE04022021_slice_80	0.773	0.190	0.130	0.782	131.8	69.1	0.587	189.1	128.7	0.425	57.1	33.0
SE04022021_slice_81	0.766	0.189	0.130	0.775	130.8	68.9	0.578	188.0	128.4	0.422	58.7	33.8
SE04022021_slice_82	0.764	0.191	0.132	0.773	131.0	69.6	0.575	190.1	130.1	0.419	59.3	34.1
SE04022021_slice_83	0.759	0.189	0.131	0.768	127.7	68.8	0.571	188.7	129.7	0.418	59.5	34.3
SE04022021_slice_84	0.749	0.188	0.131	0.758	125.9	68.6	0.563	186.9	128.9	0.417	60.3	35.0
SE04022021_slice_85	0.736	0.188	0.132	0.745	126.6	69.5	0.553	187.2	129.6	0.412	61.2	36.0
SE04022021_slice_86	0.702	0.197	0.139	0.711	133.7	75.2	0.525	195.8	136.7	0.397	63.1	39.0
SE04022021_slice_87	0.724	0.185	0.129	0.734	128.5	69.4	0.537	183.8	126.6	0.402	61.4	36.6
