GAN Evaluation Report - Patient SV03022021

Native→Venous Translation Metrics (Generated Venous vs Real Venous)

Targeted Slice 70 - Network-Normalized Analysis (Generated vs Real Venous)

0.859

SSIM Score

0.131

RMSE

0.101

MAE

Average Network-Normalized Metrics Across All Slices (99 slices) - Generated vs Real Venous

0.846

SSIM Score (Avg)

0.142

RMSE (Avg)

0.110

MAE (Avg)

Targeted Slice 70 - HU-Space Analysis (Generated vs Real Venous)

0.863

HU SSIM

100.3

HU RMSE

63.0

HU MAE

Average HU-Space Metrics Across All Slices (99 slices) - Generated vs Real Venous

0.851

HU SSIM (Avg)

101.3

HU RMSE (Avg)

64.9

HU MAE (Avg)

Targeted Slice 70 - Lung Window Analysis (Generated vs Real Venous)

0.681

Lung SSIM

130.0

Lung RMSE

99.3

Lung MAE

Average Lung Window Metrics Across All Slices (99 slices) - Generated vs Real Venous

0.674

Lung SSIM (Avg)

140.8

Lung RMSE (Avg)

107.8

Lung MAE (Avg)

Targeted Slice 70 - Mediastinum Window Analysis (Generated vs Real Venous)

0.622

Mediastinum SSIM

41.5

Mediastinum RMSE

19.8

Mediastinum MAE

Average Mediastinum Window Metrics Across All Slices (99 slices) - Generated vs Real Venous

0.606

Mediastinum SSIM (Avg)

44.2

Mediastinum RMSE (Avg)

21.8

Mediastinum MAE (Avg)

Detailed Per-Slice Metrics

Slice ID	SSIM	RMSE	MAE	HU SSIM	HU RMSE	HU MAE	Lung SSIM	Lung RMSE	Lung MAE	Mediastinum SSIM	Mediastinum RMSE	Mediastinum MAE
SV03022021_slice_0	0.854	0.145	0.111	0.859	98.9	63.2	0.679	144.0	108.7	0.581	43.3	22.1
SV03022021_slice_1	0.837	0.144	0.111	0.842	98.1	63.5	0.662	142.8	108.8	0.568	45.8	23.6
SV03022021_slice_2	0.843	0.147	0.113	0.849	98.9	63.8	0.671	146.0	110.6	0.570	44.7	23.1
SV03022021_slice_3	0.830	0.141	0.109	0.835	97.0	62.6	0.656	140.1	106.7	0.563	47.2	24.4
SV03022021_slice_4	0.833	0.149	0.115	0.839	100.2	64.7	0.660	148.2	112.5	0.559	46.9	24.3
SV03022021_slice_5	0.844	0.161	0.122	0.850	105.1	67.4	0.677	159.8	120.1	0.569	45.5	23.2
SV03022021_slice_6	0.847	0.163	0.124	0.853	105.5	67.7	0.679	161.6	121.5	0.576	45.4	23.0
SV03022021_slice_7	0.848	0.152	0.116	0.854	101.2	64.6	0.677	150.6	113.4	0.582	45.2	22.7
SV03022021_slice_8	0.849	0.148	0.113	0.855	100.8	64.3	0.676	147.5	111.2	0.590	44.2	22.3
SV03022021_slice_9	0.851	0.149	0.114	0.857	101.9	65.3	0.679	148.0	112.1	0.595	43.5	21.8
SV03022021_slice_10	0.849	0.147	0.113	0.855	102.1	65.5	0.674	145.9	111.0	0.595	44.4	21.8
SV03022021_slice_11	0.851	0.149	0.114	0.857	103.4	66.1	0.678	147.4	112.0	0.602	44.5	21.5
SV03022021_slice_12	0.851	0.146	0.112	0.857	102.1	65.0	0.679	144.5	109.6	0.609	43.3	20.8
SV03022021_slice_13	0.853	0.147	0.112	0.859	103.0	65.5	0.680	145.3	110.1	0.613	42.7	20.6
SV03022021_slice_14	0.852	0.151	0.116	0.858	106.0	67.6	0.680	150.1	114.0	0.616	42.4	20.5
SV03022021_slice_15	0.855	0.143	0.110	0.861	101.3	64.3	0.679	142.0	107.6	0.620	41.9	20.0
SV03022021_slice_16	0.853	0.147	0.113	0.859	103.7	66.6	0.680	145.2	110.8	0.620	42.5	20.5
SV03022021_slice_17	0.854	0.148	0.115	0.860	103.6	67.0	0.684	147.3	112.8	0.624	42.1	20.4
SV03022021_slice_18	0.856	0.144	0.111	0.862	100.8	64.9	0.686	142.9	109.1	0.625	41.8	20.2
SV03022021_slice_19	0.860	0.142	0.109	0.866	99.7	63.4	0.688	140.5	106.6	0.624	40.9	19.6
SV03022021_slice_20	0.860	0.143	0.109	0.866	100.6	63.6	0.687	141.5	107.0	0.625	40.9	19.4
SV03022021_slice_21	0.861	0.142	0.108	0.867	100.5	63.4	0.687	140.8	106.3	0.624	41.3	19.5
SV03022021_slice_22	0.852	0.147	0.114	0.858	104.3	67.0	0.681	146.1	111.5	0.621	42.8	20.5
SV03022021_slice_23	0.847	0.155	0.120	0.853	108.8	70.2	0.678	153.8	117.8	0.621	43.5	20.7
SV03022021_slice_24	0.840	0.159	0.124	0.847	110.8	72.4	0.674	158.1	122.1	0.619	43.9	21.3
SV03022021_slice_25	0.832	0.159	0.124	0.838	111.3	73.1	0.666	157.6	122.2	0.615	45.6	22.3
SV03022021_slice_26	0.834	0.157	0.122	0.840	110.5	71.9	0.667	156.3	120.5	0.612	45.5	22.2
SV03022021_slice_27	0.835	0.155	0.120	0.842	109.8	70.6	0.668	154.3	118.3	0.614	46.1	22.1
SV03022021_slice_28	0.839	0.154	0.119	0.845	108.9	69.9	0.671	152.6	116.8	0.621	46.0	21.9
SV03022021_slice_29	0.838	0.151	0.116	0.844	107.8	69.1	0.669	149.8	114.8	0.618	46.2	21.8
SV03022021_slice_30	0.838	0.145	0.111	0.845	103.9	66.1	0.668	144.3	110.0	0.619	45.2	21.5
SV03022021_slice_31	0.838	0.146	0.112	0.845	104.8	66.4	0.665	144.7	110.0	0.616	45.3	21.8
SV03022021_slice_32	0.834	0.143	0.109	0.841	104.3	65.5	0.659	141.7	107.4	0.610	46.1	22.3
SV03022021_slice_33	0.832	0.138	0.104	0.839	103.1	63.4	0.655	136.7	102.6	0.611	46.4	22.4
SV03022021_slice_34	0.832	0.137	0.104	0.839	102.7	63.2	0.657	136.1	102.0	0.615	46.2	22.2
SV03022021_slice_35	0.835	0.143	0.109	0.842	104.2	64.9	0.665	142.0	107.0	0.616	45.4	21.8
SV03022021_slice_36	0.836	0.142	0.108	0.842	102.8	64.6	0.667	140.5	106.4	0.619	45.5	21.7
SV03022021_slice_37	0.837	0.144	0.110	0.844	101.8	65.0	0.668	142.7	108.7	0.623	45.0	21.5
SV03022021_slice_38	0.843	0.141	0.108	0.850	100.3	64.1	0.674	139.6	106.3	0.622	44.1	21.3
SV03022021_slice_39	0.849	0.145	0.112	0.856	100.7	65.2	0.682	144.2	110.4	0.625	43.3	21.1
SV03022021_slice_40	0.849	0.149	0.116	0.856	102.4	67.1	0.685	148.1	114.0	0.625	43.4	21.3
SV03022021_slice_41	0.855	0.150	0.116	0.862	101.4	66.4	0.693	148.7	114.2	0.627	42.6	20.9
SV03022021_slice_42	0.853	0.148	0.115	0.860	102.3	66.5	0.689	147.3	113.1	0.624	43.6	21.2
SV03022021_slice_43	0.851	0.149	0.115	0.858	102.5	66.9	0.686	147.9	113.7	0.621	43.9	21.5
SV03022021_slice_44	0.853	0.146	0.112	0.860	99.6	64.4	0.692	144.8	110.6	0.622	43.9	21.5
SV03022021_slice_45	0.853	0.149	0.115	0.860	100.0	65.1	0.694	148.1	113.2	0.620	43.9	21.7
SV03022021_slice_46	0.853	0.148	0.114	0.860	99.5	64.9	0.694	147.2	112.8	0.619	44.3	21.9
SV03022021_slice_47	0.854	0.141	0.108	0.861	96.8	62.4	0.690	139.7	106.9	0.619	44.7	22.1
SV03022021_slice_48	0.855	0.141	0.109	0.862	97.7	63.3	0.692	140.5	107.9	0.622	44.8	22.0
SV03022021_slice_49	0.853	0.139	0.107	0.860	97.2	62.6	0.690	138.3	105.9	0.622	45.0	22.0
SV03022021_slice_50	0.852	0.142	0.110	0.859	100.1	64.5	0.688	141.1	108.4	0.617	44.2	21.6
SV03022021_slice_51	0.857	0.138	0.106	0.863	98.6	63.4	0.694	136.7	104.9	0.625	42.7	20.7
SV03022021_slice_52	0.855	0.133	0.103	0.861	95.8	61.6	0.693	132.0	101.2	0.630	42.2	20.6
SV03022021_slice_53	0.856	0.140	0.109	0.862	101.8	65.5	0.695	139.1	107.0	0.635	41.6	20.0
SV03022021_slice_54	0.854	0.144	0.113	0.859	106.2	68.5	0.694	143.5	110.8	0.635	41.8	19.9
SV03022021_slice_55	0.855	0.146	0.114	0.860	111.7	71.5	0.698	145.1	112.0	0.646	42.0	19.6
SV03022021_slice_56	0.854	0.150	0.118	0.858	115.5	74.2	0.700	149.1	115.5	0.648	43.0	19.7
SV03022021_slice_57	0.856	0.146	0.116	0.860	110.9	73.2	0.700	144.2	113.5	0.654	42.8	19.6
SV03022021_slice_58	0.864	0.142	0.112	0.868	109.2	71.0	0.712	141.1	110.1	0.667	40.3	18.2
SV03022021_slice_59	0.868	0.140	0.110	0.871	109.1	70.6	0.714	139.1	108.2	0.674	39.3	17.6
SV03022021_slice_60	0.872	0.134	0.106	0.875	105.1	68.5	0.714	132.9	103.7	0.677	38.6	17.2
SV03022021_slice_61	0.882	0.128	0.102	0.885	97.3	64.4	0.725	126.6	99.6	0.685	36.8	16.2
SV03022021_slice_62	0.881	0.126	0.100	0.884	97.5	64.0	0.717	124.8	97.9	0.679	37.7	16.6
SV03022021_slice_63	0.883	0.126	0.099	0.886	94.9	61.9	0.718	124.1	96.8	0.675	37.3	16.6
SV03022021_slice_64	0.883	0.125	0.098	0.886	94.6	61.0	0.715	123.5	95.7	0.669	37.1	16.5
SV03022021_slice_65	0.881	0.123	0.096	0.885	93.9	60.1	0.709	121.6	93.8	0.661	37.3	16.7
SV03022021_slice_66	0.878	0.126	0.098	0.881	95.3	60.9	0.707	124.4	95.8	0.655	37.8	17.1
SV03022021_slice_67	0.873	0.127	0.098	0.877	95.9	61.0	0.699	125.8	96.7	0.646	38.0	17.5
SV03022021_slice_68	0.863	0.124	0.096	0.867	95.0	60.3	0.686	123.1	94.6	0.638	39.8	19.0
SV03022021_slice_69	0.856	0.127	0.098	0.860	97.2	61.7	0.679	126.0	96.8	0.627	41.4	20.1
SV03022021_slice_70	0.859	0.131	0.101	0.863	100.3	63.0	0.681	130.0	99.3	0.622	41.5	19.8
SV03022021_slice_71	0.857	0.133	0.102	0.861	100.9	63.2	0.679	131.9	100.5	0.618	42.0	20.2
SV03022021_slice_72	0.852	0.132	0.102	0.856	100.6	63.4	0.672	131.4	100.5	0.609	42.9	21.0
SV03022021_slice_73	0.848	0.130	0.100	0.853	100.1	62.5	0.665	128.8	98.2	0.604	43.4	21.4
SV03022021_slice_74	0.842	0.134	0.103	0.846	101.0	63.8	0.661	132.9	102.0	0.600	44.2	22.3
SV03022021_slice_75	0.835	0.134	0.104	0.839	101.3	63.9	0.653	133.5	102.4	0.593	45.5	23.2
SV03022021_slice_76	0.829	0.137	0.106	0.833	101.9	65.0	0.650	135.9	104.8	0.588	46.2	23.8
SV03022021_slice_77	0.830	0.138	0.107	0.834	101.8	64.8	0.650	136.7	105.2	0.583	46.1	23.8
SV03022021_slice_78	0.813	0.135	0.105	0.817	100.1	64.5	0.632	134.2	104.0	0.571	48.0	25.6
SV03022021_slice_79	0.813	0.135	0.105	0.817	99.5	63.8	0.633	134.5	103.9	0.569	47.9	25.5
SV03022021_slice_80	0.815	0.136	0.105	0.819	99.2	63.4	0.629	134.8	104.0	0.561	48.2	25.6
SV03022021_slice_81	0.808	0.135	0.105	0.812	98.9	63.7	0.624	134.4	104.1	0.559	49.2	26.4
SV03022021_slice_82	0.805	0.137	0.107	0.808	100.1	64.7	0.620	136.2	105.8	0.553	49.9	26.8
SV03022021_slice_83	0.807	0.136	0.106	0.811	98.7	63.8	0.623	135.0	104.8	0.553	50.0	26.8
SV03022021_slice_84	0.793	0.135	0.105	0.797	97.8	63.7	0.613	133.7	104.3	0.549	52.3	28.4
SV03022021_slice_85	0.805	0.138	0.108	0.809	98.5	63.9	0.626	137.1	106.4	0.550	50.8	27.5
SV03022021_slice_86	0.807	0.135	0.105	0.812	96.9	62.6	0.626	133.9	103.6	0.551	50.8	27.4
SV03022021_slice_87	0.810	0.135	0.104	0.815	96.6	62.1	0.628	133.6	103.1	0.548	50.2	27.0
SV03022021_slice_88	0.829	0.137	0.106	0.833	96.2	61.8	0.646	135.9	104.4	0.557	47.7	25.4
SV03022021_slice_89	0.840	0.140	0.107	0.844	97.8	61.8	0.658	139.0	105.9	0.560	46.6	24.4
SV03022021_slice_90	0.846	0.141	0.107	0.850	97.8	61.7	0.662	139.6	106.2	0.558	45.4	23.6
SV03022021_slice_91	0.845	0.139	0.107	0.849	96.4	61.1	0.661	138.3	105.3	0.556	45.8	24.0
SV03022021_slice_92	0.836	0.139	0.106	0.840	96.9	61.5	0.652	137.5	105.2	0.552	47.3	24.9
SV03022021_slice_93	0.836	0.140	0.107	0.840	98.2	62.0	0.652	139.5	106.4	0.552	47.5	24.8
SV03022021_slice_94	0.844	0.143	0.109	0.848	99.8	62.4	0.659	142.3	107.9	0.555	46.7	24.1
SV03022021_slice_95	0.848	0.146	0.111	0.852	100.2	63.0	0.665	145.4	110.3	0.556	46.2	23.7
SV03022021_slice_96	0.850	0.147	0.113	0.854	99.6	63.3	0.668	146.5	111.5	0.559	45.3	23.4
SV03022021_slice_97	0.852	0.145	0.111	0.856	97.5	62.1	0.669	144.0	109.5	0.559	44.8	23.2
SV03022021_slice_98	0.854	0.147	0.113	0.858	98.7	63.0	0.674	146.5	111.3	0.561	44.3	23.1
