GAN Evaluation Report - Patient BC23122020

Native→Venous Translation Metrics (Generated Venous vs Real Venous)

Targeted Slice 70 - Network-Normalized Analysis (Generated vs Real Venous)

0.863

SSIM Score

0.057

RMSE

0.026

MAE

Average Network-Normalized Metrics Across All Slices (107 slices) - Generated vs Real Venous

0.874

SSIM Score (Avg)

0.050

RMSE (Avg)

0.025

MAE (Avg)

Targeted Slice 70 - HU-Space Analysis (Generated vs Real Venous)

0.863

HU SSIM

56.8

HU RMSE

25.7

HU MAE

Average HU-Space Metrics Across All Slices (107 slices) - Generated vs Real Venous

0.874

HU SSIM (Avg)

50.0

HU RMSE (Avg)

24.6

HU MAE (Avg)

Targeted Slice 70 - Lung Window Analysis (Generated vs Real Venous)

0.782

Lung SSIM

53.6

Lung RMSE

23.6

Lung MAE

Average Lung Window Metrics Across All Slices (107 slices) - Generated vs Real Venous

0.779

Lung SSIM (Avg)

45.9

Lung RMSE (Avg)

22.1

Lung MAE (Avg)

Targeted Slice 70 - Mediastinum Window Analysis (Generated vs Real Venous)

0.666

Mediastinum SSIM

56.7

Mediastinum RMSE

25.5

Mediastinum MAE

Average Mediastinum Window Metrics Across All Slices (107 slices) - Generated vs Real Venous

0.642

Mediastinum SSIM (Avg)

49.9

Mediastinum RMSE (Avg)

24.3

Mediastinum MAE (Avg)

Detailed Per-Slice Metrics

Slice ID	SSIM	RMSE	MAE	HU SSIM	HU RMSE	HU MAE	Lung SSIM	Lung RMSE	Lung MAE	Mediastinum SSIM	Mediastinum RMSE	Mediastinum MAE
BC23122020_slice_0	0.901	0.041	0.021	0.901	40.6	21.3	0.808	35.6	18.5	0.678	40.4	20.9
BC23122020_slice_1	0.899	0.041	0.021	0.899	41.2	20.6	0.806	36.1	17.7	0.673	40.9	20.2
BC23122020_slice_2	0.900	0.042	0.021	0.900	42.1	20.6	0.806	36.6	17.4	0.672	41.8	19.6
BC23122020_slice_3	0.895	0.044	0.023	0.895	43.6	22.5	0.800	38.4	19.6	0.669	43.4	22.3
BC23122020_slice_4	0.896	0.043	0.024	0.896	42.7	23.9	0.804	37.5	20.9	0.667	42.5	23.7
BC23122020_slice_5	0.898	0.042	0.022	0.898	42.0	21.7	0.806	37.4	19.0	0.672	41.8	21.5
BC23122020_slice_6	0.897	0.042	0.023	0.897	42.1	22.5	0.810	37.7	20.0	0.678	41.9	22.3
BC23122020_slice_7	0.899	0.043	0.022	0.899	42.6	22.2	0.812	37.8	19.6	0.683	42.4	22.0
BC23122020_slice_8	0.895	0.043	0.021	0.895	43.4	21.3	0.808	38.5	18.8	0.680	43.2	21.1
BC23122020_slice_9	0.891	0.044	0.024	0.891	43.9	24.0	0.804	39.0	21.4	0.674	43.7	23.9
BC23122020_slice_10	0.890	0.044	0.022	0.890	44.5	21.8	0.802	39.3	19.1	0.671	44.3	21.6
BC23122020_slice_11	0.897	0.043	0.023	0.897	43.4	22.6	0.812	38.2	19.7	0.676	43.2	22.4
BC23122020_slice_12	0.900	0.043	0.022	0.900	42.7	22.1	0.814	37.6	19.3	0.675	42.5	21.9
BC23122020_slice_13	0.898	0.043	0.021	0.898	43.0	21.1	0.813	38.1	18.4	0.679	42.8	20.8
BC23122020_slice_14	0.901	0.044	0.021	0.901	43.7	20.6	0.817	37.9	17.7	0.687	43.5	19.7
BC23122020_slice_15	0.900	0.044	0.022	0.900	43.6	21.9	0.817	38.0	18.8	0.680	43.5	21.6
BC23122020_slice_16	0.903	0.044	0.021	0.903	43.7	21.4	0.822	37.8	18.4	0.686	43.6	21.1
BC23122020_slice_17	0.898	0.045	0.022	0.898	44.5	22.1	0.816	38.9	19.1	0.680	44.4	21.9
BC23122020_slice_18	0.893	0.046	0.023	0.893	45.8	23.4	0.811	40.5	20.6	0.672	45.7	23.3
BC23122020_slice_19	0.893	0.046	0.024	0.893	45.6	24.3	0.810	40.6	21.6	0.670	45.5	24.1
BC23122020_slice_20	0.897	0.044	0.023	0.897	44.2	23.5	0.813	39.4	20.9	0.673	44.1	23.3
BC23122020_slice_21	0.898	0.044	0.024	0.898	44.1	24.0	0.815	39.2	21.3	0.672	44.0	23.9
BC23122020_slice_22	0.905	0.043	0.021	0.905	42.9	21.2	0.821	38.0	18.4	0.678	42.8	20.8
BC23122020_slice_23	0.909	0.042	0.021	0.909	42.0	21.4	0.827	36.8	18.6	0.680	41.9	21.3
BC23122020_slice_24	0.914	0.041	0.020	0.914	41.4	20.3	0.835	35.8	17.3	0.688	41.3	20.1
BC23122020_slice_25	0.912	0.042	0.020	0.912	41.7	20.0	0.831	36.4	17.1	0.690	41.6	19.3
BC23122020_slice_26	0.906	0.042	0.022	0.906	41.9	22.3	0.824	37.0	19.5	0.679	41.9	22.2
BC23122020_slice_27	0.906	0.041	0.020	0.906	41.4	20.5	0.819	36.6	17.8	0.672	41.4	20.2
BC23122020_slice_28	0.906	0.042	0.021	0.906	41.8	21.5	0.818	37.2	18.9	0.672	41.7	21.4
BC23122020_slice_29	0.905	0.043	0.021	0.905	42.7	21.0	0.819	37.5	18.3	0.674	42.6	20.8
BC23122020_slice_30	0.899	0.044	0.022	0.899	44.2	21.7	0.815	39.1	18.9	0.667	44.1	21.6
BC23122020_slice_31	0.895	0.046	0.022	0.895	45.9	22.3	0.812	40.5	19.3	0.665	45.8	22.1
BC23122020_slice_32	0.894	0.048	0.023	0.894	47.7	22.9	0.812	42.1	19.7	0.666	47.6	22.7
BC23122020_slice_33	0.894	0.048	0.023	0.894	48.3	22.8	0.814	42.4	19.5	0.669	48.2	22.6
BC23122020_slice_34	0.893	0.048	0.024	0.893	47.9	23.8	0.814	42.5	20.7	0.667	47.9	23.7
BC23122020_slice_35	0.892	0.048	0.023	0.892	48.4	23.3	0.808	43.4	20.4	0.677	48.1	21.2
BC23122020_slice_36	0.887	0.049	0.023	0.887	48.9	23.4	0.802	44.1	20.5	0.663	48.8	23.1
BC23122020_slice_37	0.884	0.051	0.024	0.884	50.5	24.1	0.797	45.5	21.0	0.656	50.4	23.7
BC23122020_slice_38	0.882	0.051	0.024	0.882	51.0	24.4	0.795	45.9	21.3	0.655	50.9	24.0
BC23122020_slice_39	0.882	0.051	0.025	0.882	50.6	25.2	0.794	45.5	22.1	0.649	50.5	25.1
BC23122020_slice_40	0.881	0.050	0.024	0.881	49.9	24.1	0.793	45.0	21.1	0.653	49.8	23.7
BC23122020_slice_41	0.880	0.052	0.025	0.880	51.5	24.6	0.791	46.1	21.4	0.655	51.4	23.5
BC23122020_slice_42	0.876	0.052	0.025	0.876	51.7	25.2	0.791	46.3	21.9	0.652	51.6	25.0
BC23122020_slice_43	0.875	0.051	0.025	0.875	51.3	24.7	0.788	46.0	21.6	0.654	51.2	24.3
BC23122020_slice_44	0.874	0.051	0.027	0.874	51.4	26.8	0.787	46.5	23.9	0.649	51.4	26.8
BC23122020_slice_45	0.876	0.051	0.025	0.876	51.4	24.8	0.786	46.5	21.9	0.650	51.3	24.4
BC23122020_slice_46	0.876	0.050	0.025	0.876	50.4	25.2	0.787	45.5	22.1	0.646	50.4	25.0
BC23122020_slice_47	0.873	0.051	0.025	0.873	50.8	24.6	0.783	46.1	21.7	0.648	50.6	24.0
BC23122020_slice_48	0.864	0.052	0.025	0.864	52.2	25.4	0.774	47.7	22.5	0.642	52.1	24.8
BC23122020_slice_49	0.857	0.055	0.027	0.857	54.6	26.8	0.767	50.1	23.9	0.642	54.5	25.4
BC23122020_slice_50	0.859	0.055	0.027	0.859	54.7	27.2	0.768	50.4	24.4	0.629	54.6	27.0
BC23122020_slice_51	0.860	0.055	0.027	0.860	55.0	27.2	0.772	50.6	24.4	0.634	54.9	27.1
BC23122020_slice_52	0.865	0.054	0.027	0.865	54.2	26.9	0.778	49.6	24.0	0.635	54.2	26.8
BC23122020_slice_53	0.869	0.053	0.026	0.869	52.9	25.9	0.779	48.7	23.3	0.637	52.8	25.8
BC23122020_slice_54	0.876	0.050	0.025	0.876	50.2	24.8	0.785	46.2	22.2	0.642	50.1	24.7
BC23122020_slice_55	0.877	0.050	0.025	0.877	50.2	24.7	0.784	45.8	22.0	0.639	50.1	24.5
BC23122020_slice_56	0.877	0.051	0.024	0.877	50.9	24.3	0.785	46.4	21.5	0.642	50.8	23.9
BC23122020_slice_57	0.881	0.051	0.024	0.881	50.7	24.5	0.790	46.0	21.5	0.642	50.7	24.2
BC23122020_slice_58	0.888	0.050	0.025	0.888	49.5	24.9	0.802	44.5	21.8	0.652	49.4	24.8
BC23122020_slice_59	0.889	0.050	0.023	0.889	50.0	23.4	0.805	44.4	20.1	0.663	49.9	23.0
BC23122020_slice_60	0.888	0.050	0.023	0.888	49.8	23.4	0.802	44.5	20.2	0.661	49.7	23.0
BC23122020_slice_61	0.890	0.050	0.023	0.890	49.6	23.0	0.804	44.3	19.9	0.669	49.4	22.4
BC23122020_slice_62	0.890	0.049	0.022	0.890	49.0	22.5	0.802	43.9	19.5	0.670	48.8	21.6
BC23122020_slice_63	0.894	0.047	0.022	0.894	47.3	22.0	0.807	42.9	19.3	0.671	47.2	21.7
BC23122020_slice_64	0.897	0.046	0.023	0.897	45.9	23.2	0.812	41.6	20.6	0.675	45.7	23.1
BC23122020_slice_65	0.896	0.047	0.022	0.896	46.9	21.6	0.808	42.9	19.1	0.684	46.6	20.3
BC23122020_slice_66	0.884	0.049	0.025	0.884	49.5	24.7	0.797	46.0	22.4	0.666	49.4	24.6
BC23122020_slice_67	0.874	0.054	0.024	0.874	53.7	23.9	0.787	50.5	21.7	0.667	53.5	23.5
BC23122020_slice_68	0.863	0.057	0.025	0.863	57.2	25.2	0.780	54.1	23.1	0.667	57.1	24.8
BC23122020_slice_69	0.857	0.058	0.026	0.857	58.1	26.2	0.774	55.1	24.3	0.662	58.0	26.0
BC23122020_slice_70	0.863	0.057	0.026	0.863	56.8	25.7	0.782	53.6	23.6	0.666	56.7	25.5
BC23122020_slice_71	0.863	0.057	0.026	0.863	56.8	25.6	0.782	53.4	23.4	0.667	56.6	25.4
BC23122020_slice_72	0.852	0.058	0.026	0.852	58.2	26.2	0.769	54.9	24.0	0.657	58.0	26.0
BC23122020_slice_73	0.857	0.057	0.026	0.857	56.9	25.8	0.768	53.9	23.7	0.649	56.7	25.6
BC23122020_slice_74	0.854	0.057	0.025	0.854	57.0	25.4	0.762	54.3	23.5	0.642	56.9	25.2
BC23122020_slice_75	0.846	0.058	0.027	0.846	57.8	26.7	0.749	55.4	24.9	0.631	57.8	26.5
BC23122020_slice_76	0.841	0.059	0.028	0.841	58.6	28.1	0.737	56.2	26.3	0.617	58.5	28.0
BC23122020_slice_77	0.838	0.060	0.027	0.838	59.7	27.0	0.731	57.4	25.3	0.613	59.6	26.8
BC23122020_slice_78	0.833	0.060	0.027	0.833	60.4	27.1	0.722	58.2	25.6	0.607	60.3	26.6
BC23122020_slice_79	0.832	0.060	0.027	0.832	60.4	27.3	0.721	58.3	25.9	0.603	60.3	27.1
BC23122020_slice_80	0.826	0.061	0.029	0.826	60.9	29.5	0.715	58.7	28.0	0.594	60.8	29.4
BC23122020_slice_81	0.830	0.061	0.029	0.830	61.0	29.0	0.715	58.8	27.6	0.588	60.9	29.0
BC23122020_slice_82	0.833	0.061	0.029	0.833	60.6	28.5	0.716	58.5	27.0	0.584	60.6	28.4
BC23122020_slice_83	0.840	0.060	0.028	0.840	60.4	28.3	0.722	58.1	26.7	0.583	60.3	28.2
BC23122020_slice_84	0.844	0.059	0.028	0.844	59.3	27.6	0.723	57.2	26.1	0.583	59.3	27.3
BC23122020_slice_85	0.849	0.058	0.028	0.849	57.9	27.5	0.728	55.8	26.0	0.580	57.9	27.4
BC23122020_slice_86	0.854	0.056	0.027	0.854	56.1	26.9	0.732	54.1	25.4	0.582	56.1	26.7
BC23122020_slice_87	0.858	0.054	0.027	0.858	54.5	27.1	0.738	52.4	25.6	0.585	54.5	27.0
BC23122020_slice_88	0.857	0.054	0.026	0.857	54.0	26.1	0.735	51.9	24.7	0.587	53.9	25.5
BC23122020_slice_89	0.854	0.054	0.027	0.854	53.8	26.8	0.733	51.5	25.4	0.579	53.8	26.7
BC23122020_slice_90	0.855	0.053	0.026	0.855	53.2	26.1	0.733	51.1	24.7	0.584	53.1	25.6
BC23122020_slice_91	0.856	0.052	0.026	0.856	52.4	25.9	0.736	50.2	24.5	0.584	52.4	25.6
BC23122020_slice_92	0.857	0.051	0.026	0.857	51.4	26.2	0.738	49.2	24.8	0.579	51.4	26.1
BC23122020_slice_93	0.852	0.052	0.026	0.852	52.2	26.1	0.733	49.9	24.7	0.581	52.2	25.9
BC23122020_slice_94	0.849	0.053	0.027	0.849	52.7	26.6	0.730	50.1	25.1	0.580	52.7	26.5
BC23122020_slice_95	0.842	0.054	0.028	0.842	54.2	27.9	0.723	51.1	26.2	0.577	54.2	27.8
BC23122020_slice_96	0.837	0.054	0.028	0.837	54.2	27.7	0.719	51.0	25.9	0.579	54.2	27.4
BC23122020_slice_97	0.843	0.052	0.028	0.843	52.4	27.9	0.726	49.2	26.2	0.580	52.4	27.9
BC23122020_slice_98	0.846	0.051	0.027	0.846	51.3	26.8	0.728	48.2	25.0	0.584	51.3	26.6
BC23122020_slice_99	0.845	0.051	0.028	0.845	50.6	28.0	0.728	47.7	26.4	0.580	50.6	28.0
BC23122020_slice_100	0.848	0.050	0.026	0.848	50.1	26.3	0.731	47.1	24.7	0.587	50.1	26.1
BC23122020_slice_101	0.846	0.050	0.026	0.846	50.3	26.1	0.732	47.2	24.4	0.593	50.3	25.7
BC23122020_slice_102	0.844	0.051	0.027	0.844	50.8	26.8	0.730	47.7	25.1	0.592	50.8	26.6
BC23122020_slice_103	0.839	0.051	0.027	0.839	51.4	26.8	0.728	48.2	25.0	0.598	51.4	26.6
BC23122020_slice_104	0.842	0.051	0.027	0.842	50.9	26.7	0.730	47.4	24.8	0.599	50.8	26.5
BC23122020_slice_105	0.850	0.049	0.026	0.850	49.1	25.6	0.735	45.7	23.7	0.602	49.0	25.2
BC23122020_slice_106	0.852	0.049	0.026	0.852	48.8	25.6	0.735	45.6	23.8	0.605	48.7	24.3
