GAN Evaluation Report - Patient BM26032018

Native→Venous Translation Metrics (Generated Venous vs Real Venous)

Targeted Slice 70 - Network-Normalized Analysis (Generated vs Real Venous)

0.916

SSIM Score

0.044

RMSE

0.019

MAE

Average Network-Normalized Metrics Across All Slices (133 slices) - Generated vs Real Venous

0.911

SSIM Score (Avg)

0.045

RMSE (Avg)

0.018

MAE (Avg)

Targeted Slice 70 - HU-Space Analysis (Generated vs Real Venous)

0.916

HU SSIM

44.0

HU RMSE

19.3

HU MAE

Average HU-Space Metrics Across All Slices (133 slices) - Generated vs Real Venous

0.911

HU SSIM (Avg)

44.6

HU RMSE (Avg)

18.3

HU MAE (Avg)

Targeted Slice 70 - Lung Window Analysis (Generated vs Real Venous)

0.852

Lung SSIM

38.4

Lung RMSE

16.6

Lung MAE

Average Lung Window Metrics Across All Slices (133 slices) - Generated vs Real Venous

0.841

Lung SSIM (Avg)

39.8

Lung RMSE (Avg)

16.1

Lung MAE (Avg)

Targeted Slice 70 - Mediastinum Window Analysis (Generated vs Real Venous)

0.734

Mediastinum SSIM

43.6

Mediastinum RMSE

19.0

Mediastinum MAE

Average Mediastinum Window Metrics Across All Slices (133 slices) - Generated vs Real Venous

0.730

Mediastinum SSIM (Avg)

44.1

Mediastinum RMSE (Avg)

17.3

Mediastinum MAE (Avg)

Detailed Per-Slice Metrics

Slice ID	SSIM	RMSE	MAE	HU SSIM	HU RMSE	HU MAE	Lung SSIM	Lung RMSE	Lung MAE	Mediastinum SSIM	Mediastinum RMSE	Mediastinum MAE
BM26032018_slice_0	0.899	0.045	0.020	0.899	44.5	19.7	0.819	39.2	17.2	0.696	44.2	19.3
BM26032018_slice_1	0.897	0.044	0.020	0.897	44.2	19.7	0.817	39.4	17.5	0.694	43.9	19.2
BM26032018_slice_2	0.896	0.045	0.021	0.896	45.1	20.5	0.815	40.0	18.3	0.689	44.8	20.2
BM26032018_slice_3	0.893	0.047	0.021	0.893	46.7	20.8	0.814	41.0	18.3	0.693	46.4	20.4
BM26032018_slice_4	0.891	0.048	0.021	0.891	48.5	21.4	0.815	41.7	18.5	0.694	48.1	20.9
BM26032018_slice_5	0.888	0.051	0.022	0.888	50.7	21.8	0.812	43.1	18.7	0.693	50.3	21.3
BM26032018_slice_6	0.888	0.050	0.022	0.888	50.1	21.6	0.813	42.8	18.6	0.694	49.8	21.1
BM26032018_slice_7	0.892	0.049	0.021	0.892	48.8	20.8	0.815	41.9	18.0	0.696	48.4	20.3
BM26032018_slice_8	0.897	0.047	0.020	0.897	47.0	19.7	0.820	40.6	17.1	0.699	46.6	19.0
BM26032018_slice_9	0.904	0.045	0.019	0.904	44.6	18.8	0.826	39.1	16.5	0.705	44.2	18.1
BM26032018_slice_10	0.908	0.043	0.018	0.908	43.5	18.4	0.830	38.4	16.2	0.713	43.0	17.2
BM26032018_slice_11	0.909	0.044	0.018	0.909	43.7	18.2	0.831	38.5	16.1	0.712	43.2	17.4
BM26032018_slice_12	0.912	0.044	0.018	0.912	43.9	18.0	0.835	38.4	15.8	0.715	43.3	17.0
BM26032018_slice_13	0.910	0.045	0.018	0.910	44.9	18.2	0.834	39.1	16.0	0.716	44.2	17.3
BM26032018_slice_14	0.908	0.045	0.018	0.908	45.3	18.4	0.833	39.8	16.2	0.717	44.8	17.6
BM26032018_slice_15	0.908	0.046	0.019	0.908	45.6	18.6	0.835	39.9	16.3	0.720	45.0	17.7
BM26032018_slice_16	0.912	0.045	0.018	0.912	44.8	18.0	0.839	39.2	15.8	0.723	44.4	17.3
BM26032018_slice_17	0.910	0.045	0.018	0.910	45.0	18.2	0.837	39.3	16.0	0.722	44.4	17.4
BM26032018_slice_18	0.911	0.045	0.019	0.911	44.9	18.5	0.839	39.3	16.3	0.727	44.3	17.0
BM26032018_slice_19	0.912	0.045	0.019	0.912	44.8	18.5	0.841	39.0	16.3	0.723	44.3	18.1
BM26032018_slice_20	0.912	0.045	0.018	0.912	45.5	18.3	0.841	39.6	16.1	0.726	45.0	17.8
BM26032018_slice_21	0.911	0.046	0.018	0.911	45.8	18.4	0.839	39.8	16.2	0.724	45.2	17.9
BM26032018_slice_22	0.913	0.046	0.018	0.913	45.5	17.9	0.841	39.4	15.6	0.731	44.9	16.9
BM26032018_slice_23	0.911	0.046	0.018	0.911	45.6	18.0	0.838	39.7	15.8	0.727	45.0	17.2
BM26032018_slice_24	0.913	0.045	0.018	0.913	45.4	17.9	0.840	39.5	15.7	0.733	44.8	16.3
BM26032018_slice_25	0.911	0.045	0.018	0.911	45.5	18.0	0.838	39.7	15.9	0.732	44.9	16.9
BM26032018_slice_26	0.910	0.045	0.018	0.910	45.2	18.0	0.837	39.7	15.9	0.728	44.7	17.3
BM26032018_slice_27	0.910	0.045	0.018	0.910	44.8	18.1	0.838	39.5	16.1	0.724	44.3	17.6
BM26032018_slice_28	0.911	0.044	0.018	0.911	44.5	17.9	0.839	39.3	15.9	0.728	44.0	17.3
BM26032018_slice_29	0.911	0.045	0.018	0.911	44.7	18.0	0.840	39.5	16.0	0.727	44.3	17.6
BM26032018_slice_30	0.912	0.045	0.018	0.912	45.4	18.0	0.841	39.9	15.9	0.734	44.9	17.1
BM26032018_slice_31	0.911	0.046	0.019	0.911	45.6	18.5	0.840	39.9	16.3	0.725	45.1	18.1
BM26032018_slice_32	0.912	0.046	0.018	0.912	45.8	18.2	0.839	40.0	16.0	0.726	45.3	17.8
BM26032018_slice_33	0.911	0.046	0.018	0.911	46.2	17.9	0.838	40.4	15.8	0.731	45.7	17.1
BM26032018_slice_34	0.911	0.046	0.018	0.911	45.9	18.2	0.837	40.1	16.0	0.726	45.4	17.7
BM26032018_slice_35	0.910	0.045	0.018	0.910	45.5	17.9	0.834	40.0	15.8	0.729	45.0	17.0
BM26032018_slice_36	0.907	0.046	0.018	0.907	45.5	18.4	0.833	40.4	16.4	0.723	45.1	18.0
BM26032018_slice_37	0.908	0.045	0.018	0.908	45.5	18.1	0.835	40.5	16.1	0.732	45.0	17.1
BM26032018_slice_38	0.911	0.045	0.018	0.911	45.0	18.2	0.838	40.3	16.1	0.737	44.5	16.5
BM26032018_slice_39	0.908	0.045	0.018	0.908	45.1	18.2	0.836	40.3	16.1	0.729	44.7	17.3
BM26032018_slice_40	0.909	0.046	0.019	0.909	45.5	18.8	0.836	40.5	16.7	0.735	44.9	16.8
BM26032018_slice_41	0.910	0.046	0.018	0.910	45.9	18.3	0.837	40.4	16.1	0.735	45.3	16.8
BM26032018_slice_42	0.908	0.047	0.019	0.908	46.6	18.6	0.836	40.6	16.2	0.735	45.9	17.2
BM26032018_slice_43	0.908	0.047	0.019	0.908	46.7	18.5	0.836	40.5	16.0	0.733	46.1	17.5
BM26032018_slice_44	0.907	0.047	0.019	0.907	46.9	18.6	0.835	40.6	16.1	0.734	46.3	17.6
BM26032018_slice_45	0.908	0.046	0.018	0.908	46.5	18.4	0.836	40.3	15.9	0.734	45.9	17.5
BM26032018_slice_46	0.907	0.046	0.019	0.907	46.3	18.9	0.836	40.4	16.4	0.730	45.9	18.4
BM26032018_slice_47	0.912	0.044	0.018	0.912	44.3	18.0	0.843	38.8	15.6	0.738	43.8	17.5
BM26032018_slice_48	0.914	0.044	0.018	0.914	44.1	17.8	0.845	38.9	15.5	0.741	43.7	17.1
BM26032018_slice_49	0.914	0.044	0.018	0.914	44.3	17.8	0.845	39.0	15.4	0.744	43.9	16.8
BM26032018_slice_50	0.914	0.045	0.018	0.914	44.8	18.3	0.845	39.2	15.8	0.746	44.2	16.4
BM26032018_slice_51	0.913	0.045	0.018	0.913	44.6	18.0	0.843	39.4	15.6	0.744	44.1	16.7
BM26032018_slice_52	0.909	0.046	0.018	0.909	46.0	18.4	0.838	40.4	16.0	0.738	45.3	17.4
BM26032018_slice_53	0.908	0.046	0.019	0.908	45.9	18.6	0.837	40.4	16.3	0.735	45.1	17.9
BM26032018_slice_54	0.907	0.046	0.019	0.907	46.3	18.9	0.836	40.8	16.5	0.731	45.6	18.4
BM26032018_slice_55	0.907	0.046	0.019	0.907	46.1	18.8	0.836	40.6	16.4	0.733	45.6	18.3
BM26032018_slice_56	0.907	0.046	0.019	0.907	46.1	18.7	0.838	40.6	16.2	0.739	45.6	18.1
BM26032018_slice_57	0.906	0.047	0.019	0.906	46.6	19.0	0.837	41.1	16.5	0.739	46.2	18.3
BM26032018_slice_58	0.905	0.047	0.019	0.905	47.0	19.2	0.837	41.3	16.5	0.740	46.7	18.5
BM26032018_slice_59	0.909	0.046	0.019	0.909	46.1	18.9	0.841	40.3	16.2	0.740	45.8	18.3
BM26032018_slice_60	0.908	0.046	0.019	0.908	46.5	19.1	0.841	40.3	16.2	0.740	46.1	18.3
BM26032018_slice_61	0.908	0.046	0.019	0.908	46.2	18.9	0.841	40.2	16.1	0.740	45.7	17.9
BM26032018_slice_62	0.912	0.045	0.018	0.912	44.9	18.5	0.845	39.2	15.8	0.740	44.5	17.8
BM26032018_slice_63	0.911	0.045	0.018	0.911	45.5	18.5	0.844	39.9	15.9	0.744	45.0	17.3
BM26032018_slice_64	0.911	0.045	0.018	0.911	44.9	18.3	0.844	39.8	15.8	0.743	44.4	17.2
BM26032018_slice_65	0.914	0.044	0.018	0.914	44.4	18.4	0.848	39.4	15.8	0.751	43.9	16.7
BM26032018_slice_66	0.915	0.044	0.018	0.915	43.5	18.1	0.850	38.4	15.6	0.738	43.1	17.7
BM26032018_slice_67	0.915	0.044	0.018	0.915	43.8	17.9	0.848	38.5	15.4	0.737	43.2	17.3
BM26032018_slice_68	0.916	0.044	0.018	0.916	43.6	17.9	0.850	38.5	15.3	0.741	43.1	17.3
BM26032018_slice_69	0.914	0.044	0.018	0.914	44.3	18.1	0.849	39.0	15.5	0.747	43.8	16.9
BM26032018_slice_70	0.916	0.044	0.019	0.916	44.0	19.3	0.852	38.4	16.6	0.734	43.6	19.0
BM26032018_slice_71	0.920	0.043	0.018	0.920	43.4	17.6	0.857	37.7	14.9	0.751	42.9	16.8
BM26032018_slice_72	0.921	0.043	0.018	0.921	42.8	17.8	0.859	37.3	15.1	0.749	42.4	17.3
BM26032018_slice_73	0.916	0.045	0.018	0.916	44.8	18.3	0.855	38.9	15.4	0.751	44.4	17.1
BM26032018_slice_74	0.914	0.045	0.019	0.914	44.9	18.5	0.852	39.1	15.7	0.743	44.6	18.0
BM26032018_slice_75	0.915	0.044	0.018	0.915	44.2	18.2	0.852	38.9	15.6	0.743	43.9	17.7
BM26032018_slice_76	0.916	0.044	0.018	0.916	43.8	17.9	0.852	38.8	15.4	0.747	43.4	17.2
BM26032018_slice_77	0.918	0.043	0.018	0.918	43.1	17.6	0.855	38.2	15.2	0.747	42.7	16.9
BM26032018_slice_78	0.920	0.042	0.017	0.920	42.5	17.3	0.857	37.5	14.8	0.750	42.0	16.5
BM26032018_slice_79	0.918	0.043	0.017	0.918	42.6	17.4	0.855	37.8	15.0	0.747	42.2	16.8
BM26032018_slice_80	0.915	0.044	0.018	0.915	44.1	17.8	0.851	38.7	15.2	0.747	43.5	16.7
BM26032018_slice_81	0.916	0.044	0.018	0.916	43.9	17.5	0.853	38.4	15.0	0.752	43.2	16.4
BM26032018_slice_82	0.920	0.042	0.018	0.920	42.4	17.6	0.858	37.4	15.2	0.747	41.9	17.3
BM26032018_slice_83	0.921	0.043	0.017	0.921	43.2	17.0	0.860	37.8	14.5	0.763	42.5	15.9
BM26032018_slice_84	0.922	0.043	0.017	0.922	42.6	17.1	0.861	37.6	14.7	0.756	42.2	16.6
BM26032018_slice_85	0.917	0.044	0.018	0.917	44.4	18.1	0.854	39.1	15.6	0.764	43.6	15.8
BM26032018_slice_86	0.913	0.045	0.018	0.913	44.9	17.9	0.849	40.2	15.5	0.750	44.5	17.1
BM26032018_slice_87	0.906	0.046	0.019	0.906	46.5	18.8	0.844	42.3	16.5	0.743	46.1	18.2
BM26032018_slice_88	0.904	0.047	0.019	0.904	47.0	18.8	0.842	42.8	16.7	0.743	46.4	18.2
BM26032018_slice_89	0.904	0.047	0.018	0.904	46.9	18.5	0.840	42.9	16.4	0.748	46.3	17.2
BM26032018_slice_90	0.906	0.046	0.018	0.906	45.9	18.3	0.841	42.0	16.4	0.742	45.3	17.8
BM26032018_slice_91	0.904	0.046	0.018	0.904	46.2	18.2	0.838	42.4	16.4	0.745	45.6	17.2
BM26032018_slice_92	0.904	0.046	0.018	0.904	46.2	18.3	0.838	42.7	16.7	0.751	45.6	16.7
BM26032018_slice_93	0.905	0.046	0.018	0.905	46.1	18.0	0.841	42.6	16.4	0.749	45.5	17.0
BM26032018_slice_94	0.910	0.044	0.017	0.910	44.3	17.2	0.845	41.3	15.7	0.753	43.9	16.3
BM26032018_slice_95	0.914	0.043	0.017	0.914	43.3	16.6	0.849	40.4	15.2	0.756	42.8	15.5
BM26032018_slice_96	0.918	0.042	0.016	0.918	41.6	16.0	0.854	38.9	14.7	0.753	41.2	15.5
BM26032018_slice_97	0.918	0.042	0.016	0.918	41.7	16.2	0.853	38.6	14.7	0.749	41.3	15.5
BM26032018_slice_98	0.910	0.044	0.017	0.910	44.0	17.3	0.847	41.0	15.8	0.743	43.6	16.7
BM26032018_slice_99	0.913	0.044	0.017	0.913	43.7	16.7	0.848	40.7	15.3	0.748	43.3	15.8
BM26032018_slice_100	0.916	0.043	0.017	0.916	43.1	17.0	0.851	40.2	15.6	0.754	42.5	14.9
BM26032018_slice_101	0.921	0.041	0.016	0.921	41.2	16.0	0.856	38.4	14.5	0.754	40.8	14.6
BM26032018_slice_102	0.924	0.040	0.016	0.924	40.3	15.7	0.858	37.4	14.3	0.752	39.9	14.3
BM26032018_slice_103	0.923	0.040	0.016	0.923	40.3	15.8	0.857	37.5	14.4	0.750	39.8	14.5
BM26032018_slice_104	0.924	0.040	0.016	0.924	39.9	15.7	0.858	37.1	14.3	0.747	39.6	14.7
BM26032018_slice_105	0.922	0.041	0.016	0.922	40.8	16.1	0.857	37.8	14.5	0.740	40.4	15.1
BM26032018_slice_106	0.923	0.040	0.016	0.923	40.3	16.1	0.858	37.3	14.5	0.741	39.9	14.8
BM26032018_slice_107	0.921	0.042	0.019	0.921	42.1	18.8	0.855	38.8	17.0	0.741	41.4	15.1
BM26032018_slice_108	0.923	0.041	0.017	0.923	40.9	16.8	0.857	37.5	15.0	0.738	40.5	15.0
BM26032018_slice_109	0.921	0.041	0.018	0.921	41.3	17.5	0.855	38.0	15.7	0.736	40.9	15.2
BM26032018_slice_110	0.920	0.042	0.018	0.920	41.6	18.4	0.854	38.4	16.6	0.734	41.1	15.4
BM26032018_slice_111	0.917	0.043	0.019	0.917	42.6	19.2	0.851	39.2	17.3	0.732	42.0	15.8
BM26032018_slice_112	0.916	0.043	0.019	0.916	42.7	18.9	0.847	39.4	17.0	0.725	42.2	16.1
BM26032018_slice_113	0.917	0.043	0.019	0.917	42.7	19.2	0.848	39.2	17.4	0.724	42.1	16.0
BM26032018_slice_114	0.919	0.042	0.018	0.919	41.8	17.9	0.848	38.5	16.1	0.720	41.4	15.9
BM26032018_slice_115	0.919	0.042	0.017	0.919	41.6	17.5	0.848	38.3	15.7	0.717	41.3	15.9
BM26032018_slice_116	0.919	0.042	0.018	0.919	41.7	17.9	0.846	38.4	16.1	0.715	41.4	16.2
BM26032018_slice_117	0.915	0.043	0.019	0.915	42.8	18.8	0.841	39.3	16.9	0.710	42.5	16.8
BM26032018_slice_118	0.915	0.043	0.019	0.915	43.0	18.9	0.842	39.4	17.0	0.711	42.6	16.8
BM26032018_slice_119	0.916	0.043	0.019	0.916	42.7	18.8	0.843	39.1	16.9	0.712	42.4	16.9
BM26032018_slice_120	0.915	0.043	0.019	0.915	43.2	18.8	0.842	39.3	16.9	0.709	42.9	17.1
BM26032018_slice_121	0.913	0.044	0.019	0.913	44.1	19.4	0.838	40.1	17.4	0.706	43.8	17.3
BM26032018_slice_122	0.914	0.044	0.019	0.914	43.5	18.8	0.837	39.6	16.9	0.706	43.3	17.4
BM26032018_slice_123	0.913	0.043	0.018	0.913	43.2	18.4	0.835	39.5	16.6	0.702	43.0	17.5
BM26032018_slice_124	0.912	0.044	0.019	0.912	43.6	18.6	0.834	39.8	16.8	0.698	43.5	18.2
BM26032018_slice_125	0.911	0.044	0.019	0.911	44.3	18.9	0.832	40.4	17.1	0.697	44.2	18.5
BM26032018_slice_126	0.907	0.046	0.019	0.907	45.8	19.2	0.826	41.6	17.5	0.700	45.6	18.3
BM26032018_slice_127	0.903	0.047	0.019	0.903	46.7	19.4	0.822	42.4	17.7	0.696	46.5	18.7
BM26032018_slice_128	0.901	0.047	0.020	0.901	47.2	19.6	0.820	43.0	18.1	0.698	46.8	18.5
BM26032018_slice_129	0.899	0.047	0.019	0.899	46.9	19.4	0.818	43.2	18.0	0.699	46.6	18.3
BM26032018_slice_130	0.897	0.046	0.019	0.897	46.3	19.5	0.817	42.8	18.1	0.694	46.0	19.0
BM26032018_slice_131	0.900	0.045	0.019	0.900	44.6	19.0	0.819	41.7	17.7	0.696	44.3	18.3
BM26032018_slice_132	0.902	0.044	0.019	0.902	43.5	18.8	0.821	40.6	17.5	0.695	43.2	18.3
