GAN Evaluation Report - Patient PP08072020

Native→Venous Translation Metrics (Generated Venous vs Real Venous)

Targeted Slice 70 - Network-Normalized Analysis (Generated vs Real Venous)

0.929

SSIM Score

0.037

RMSE

0.015

MAE

Average Network-Normalized Metrics Across All Slices (112 slices) - Generated vs Real Venous

0.914

SSIM Score (Avg)

0.039

RMSE (Avg)

0.018

MAE (Avg)

Targeted Slice 70 - HU-Space Analysis (Generated vs Real Venous)

0.929

HU SSIM

37.2

HU RMSE

15.0

HU MAE

Average HU-Space Metrics Across All Slices (112 slices) - Generated vs Real Venous

0.914

HU SSIM (Avg)

39.5

HU RMSE (Avg)

17.6

HU MAE (Avg)

Targeted Slice 70 - Lung Window Analysis (Generated vs Real Venous)

0.874

Lung SSIM

32.9

Lung RMSE

13.2

Lung MAE

Average Lung Window Metrics Across All Slices (112 slices) - Generated vs Real Venous

0.849

Lung SSIM (Avg)

35.6

Lung RMSE (Avg)

15.7

Lung MAE (Avg)

Targeted Slice 70 - Mediastinum Window Analysis (Generated vs Real Venous)

0.783

Mediastinum SSIM

36.8

Mediastinum RMSE

14.5

Mediastinum MAE

Average Mediastinum Window Metrics Across All Slices (112 slices) - Generated vs Real Venous

0.741

Mediastinum SSIM (Avg)

39.1

Mediastinum RMSE (Avg)

17.1

Mediastinum MAE (Avg)

Detailed Per-Slice Metrics

Slice ID	SSIM	RMSE	MAE	HU SSIM	HU RMSE	HU MAE	Lung SSIM	Lung RMSE	Lung MAE	Mediastinum SSIM	Mediastinum RMSE	Mediastinum MAE
PP08072020_slice_0	0.912	0.039	0.019	0.912	38.7	18.5	0.829	33.3	15.7	0.700	38.3	18.1
PP08072020_slice_1	0.903	0.044	0.020	0.903	43.6	20.1	0.817	37.6	17.2	0.690	43.1	19.7
PP08072020_slice_2	0.897	0.047	0.021	0.897	46.7	20.7	0.813	39.6	17.3	0.688	46.4	20.1
PP08072020_slice_3	0.898	0.046	0.020	0.898	45.7	20.2	0.814	39.6	17.1	0.692	45.6	19.5
PP08072020_slice_4	0.900	0.047	0.020	0.900	47.3	20.4	0.818	40.6	17.5	0.692	47.2	20.2
PP08072020_slice_5	0.915	0.039	0.018	0.915	38.9	18.2	0.836	34.1	15.6	0.704	38.8	18.0
PP08072020_slice_6	0.921	0.036	0.017	0.921	36.2	17.4	0.843	31.9	14.9	0.710	36.0	17.1
PP08072020_slice_7	0.919	0.036	0.017	0.919	36.3	17.2	0.843	31.8	14.7	0.713	36.1	16.9
PP08072020_slice_8	0.920	0.036	0.017	0.920	35.6	16.5	0.846	31.4	14.0	0.721	35.4	15.9
PP08072020_slice_9	0.930	0.034	0.016	0.930	33.7	16.0	0.859	29.6	13.6	0.732	33.5	15.7
PP08072020_slice_10	0.931	0.034	0.016	0.931	33.8	15.9	0.865	29.7	13.4	0.740	33.6	15.6
PP08072020_slice_11	0.931	0.035	0.016	0.931	34.7	15.5	0.866	30.2	13.0	0.744	34.5	15.0
PP08072020_slice_12	0.931	0.035	0.016	0.931	35.0	15.9	0.866	30.5	13.4	0.743	34.7	15.6
PP08072020_slice_13	0.930	0.035	0.016	0.930	35.2	16.2	0.862	31.0	14.1	0.740	35.0	16.0
PP08072020_slice_14	0.921	0.036	0.018	0.921	36.2	17.7	0.852	32.3	15.7	0.736	36.0	17.6
PP08072020_slice_15	0.915	0.038	0.017	0.915	38.3	17.2	0.845	33.7	15.1	0.734	37.9	16.8
PP08072020_slice_16	0.919	0.037	0.018	0.919	37.5	17.6	0.848	33.4	15.7	0.734	37.1	17.4
PP08072020_slice_17	0.921	0.037	0.018	0.921	36.8	17.6	0.853	32.7	15.6	0.740	36.5	17.3
PP08072020_slice_18	0.924	0.037	0.017	0.924	36.6	16.5	0.856	32.2	14.4	0.746	36.2	16.2
PP08072020_slice_19	0.922	0.037	0.017	0.922	37.0	16.7	0.855	32.7	14.5	0.748	36.7	16.2
PP08072020_slice_20	0.921	0.038	0.017	0.921	37.9	16.8	0.854	33.4	14.7	0.746	37.5	16.4
PP08072020_slice_21	0.920	0.037	0.017	0.920	37.0	16.5	0.853	33.0	14.6	0.745	36.6	16.1
PP08072020_slice_22	0.918	0.037	0.017	0.918	37.0	17.5	0.850	33.6	15.7	0.741	36.6	17.2
PP08072020_slice_23	0.918	0.038	0.018	0.918	37.6	17.6	0.852	33.9	15.9	0.744	37.0	17.3
PP08072020_slice_24	0.915	0.038	0.017	0.915	38.5	17.0	0.853	34.5	15.2	0.752	37.9	16.5
PP08072020_slice_25	0.920	0.038	0.017	0.920	38.1	16.9	0.859	34.1	15.1	0.756	37.7	16.5
PP08072020_slice_26	0.924	0.038	0.016	0.924	37.9	16.1	0.863	33.5	14.2	0.763	37.3	15.4
PP08072020_slice_27	0.926	0.038	0.017	0.926	37.8	16.6	0.864	33.2	14.6	0.757	37.4	16.3
PP08072020_slice_28	0.919	0.039	0.017	0.919	39.0	16.9	0.856	34.0	14.7	0.752	38.6	16.5
PP08072020_slice_29	0.910	0.041	0.018	0.910	41.2	17.5	0.846	36.0	15.3	0.751	40.7	16.8
PP08072020_slice_30	0.906	0.042	0.019	0.906	41.6	18.8	0.844	36.5	16.6	0.746	41.1	18.5
PP08072020_slice_31	0.907	0.041	0.019	0.907	40.5	19.4	0.845	36.1	17.4	0.748	40.2	19.1
PP08072020_slice_32	0.912	0.039	0.018	0.912	39.3	17.7	0.849	35.1	15.8	0.753	38.9	17.3
PP08072020_slice_33	0.913	0.041	0.018	0.913	40.7	18.3	0.850	36.1	16.3	0.750	40.3	18.0
PP08072020_slice_34	0.921	0.039	0.017	0.921	38.8	17.1	0.858	34.3	15.1	0.755	38.4	16.7
PP08072020_slice_35	0.922	0.038	0.017	0.922	38.1	16.7	0.858	33.9	14.7	0.756	37.8	16.4
PP08072020_slice_36	0.918	0.039	0.016	0.918	38.5	16.4	0.853	34.4	14.4	0.756	38.1	15.5
PP08072020_slice_37	0.916	0.039	0.018	0.916	39.2	17.7	0.851	35.2	15.6	0.749	38.9	17.4
PP08072020_slice_38	0.917	0.039	0.017	0.917	39.4	16.9	0.853	35.5	14.9	0.756	39.1	16.2
PP08072020_slice_39	0.912	0.040	0.018	0.912	40.4	18.3	0.849	36.1	16.3	0.747	40.1	18.0
PP08072020_slice_40	0.916	0.038	0.017	0.916	38.4	17.5	0.851	34.5	15.7	0.748	38.1	17.2
PP08072020_slice_41	0.921	0.037	0.017	0.921	37.2	16.6	0.858	33.2	14.8	0.757	36.7	16.3
PP08072020_slice_42	0.908	0.040	0.018	0.908	39.9	17.6	0.843	35.4	15.6	0.747	39.5	17.3
PP08072020_slice_43	0.902	0.042	0.018	0.902	41.6	18.3	0.838	36.7	16.1	0.747	41.2	17.9
PP08072020_slice_44	0.907	0.042	0.019	0.907	41.7	19.0	0.840	36.2	16.6	0.758	40.9	16.1
PP08072020_slice_45	0.908	0.041	0.018	0.908	41.3	17.7	0.843	35.9	15.5	0.753	40.8	17.1
PP08072020_slice_46	0.903	0.043	0.018	0.903	42.7	18.5	0.837	37.1	16.1	0.743	42.2	17.9
PP08072020_slice_47	0.898	0.043	0.019	0.898	43.3	18.9	0.832	38.3	16.7	0.739	42.9	18.3
PP08072020_slice_48	0.900	0.042	0.018	0.900	41.6	18.3	0.833	37.3	16.3	0.740	41.1	17.6
PP08072020_slice_49	0.899	0.042	0.020	0.899	42.0	19.6	0.831	38.3	17.8	0.734	41.7	19.3
PP08072020_slice_50	0.896	0.044	0.019	0.896	43.9	19.4	0.828	40.4	17.7	0.733	43.5	18.9
PP08072020_slice_51	0.909	0.040	0.019	0.909	40.2	19.2	0.841	36.8	17.5	0.740	39.8	18.9
PP08072020_slice_52	0.917	0.038	0.017	0.917	37.9	17.2	0.850	34.5	15.6	0.751	37.5	16.9
PP08072020_slice_53	0.908	0.040	0.019	0.908	40.3	19.2	0.842	36.6	17.4	0.742	39.8	18.9
PP08072020_slice_54	0.908	0.040	0.019	0.908	40.4	19.0	0.844	36.2	17.2	0.745	39.9	18.7
PP08072020_slice_55	0.910	0.041	0.020	0.910	40.6	19.6	0.846	36.2	17.7	0.746	40.1	19.3
PP08072020_slice_56	0.906	0.042	0.020	0.906	41.9	19.9	0.843	36.8	17.8	0.742	41.3	19.6
PP08072020_slice_57	0.904	0.042	0.018	0.904	42.5	18.2	0.844	37.2	16.0	0.750	41.7	17.6
PP08072020_slice_58	0.901	0.044	0.019	0.901	43.9	18.6	0.839	38.6	16.5	0.746	43.3	17.9
PP08072020_slice_59	0.901	0.044	0.020	0.901	43.9	19.6	0.839	39.0	17.6	0.738	43.4	19.3
PP08072020_slice_60	0.900	0.044	0.021	0.900	44.1	20.8	0.837	39.3	18.9	0.734	43.6	20.6
PP08072020_slice_61	0.906	0.043	0.019	0.906	42.7	19.0	0.841	38.3	17.1	0.738	42.2	18.7
PP08072020_slice_62	0.912	0.041	0.018	0.912	41.2	18.2	0.848	36.9	16.4	0.745	40.7	17.9
PP08072020_slice_63	0.920	0.039	0.017	0.920	39.2	16.6	0.858	34.8	14.7	0.757	38.6	16.1
PP08072020_slice_64	0.926	0.037	0.017	0.926	37.3	16.6	0.866	33.4	14.8	0.763	36.9	16.3
PP08072020_slice_65	0.933	0.035	0.015	0.933	34.6	15.1	0.877	31.2	13.4	0.775	34.2	14.7
PP08072020_slice_66	0.934	0.034	0.014	0.934	33.9	14.5	0.879	30.8	12.9	0.781	33.4	13.9
PP08072020_slice_67	0.935	0.034	0.015	0.935	33.7	14.7	0.879	30.6	13.1	0.778	33.3	14.3
PP08072020_slice_68	0.934	0.035	0.015	0.934	34.6	14.6	0.880	31.2	12.9	0.782	34.1	14.1
PP08072020_slice_69	0.934	0.035	0.014	0.934	35.4	14.1	0.879	31.5	12.4	0.790	34.9	13.2
PP08072020_slice_70	0.929	0.037	0.015	0.929	37.2	15.0	0.874	32.9	13.2	0.783	36.8	14.5
PP08072020_slice_71	0.928	0.037	0.015	0.928	37.4	14.7	0.873	33.1	13.0	0.787	36.9	13.9
PP08072020_slice_72	0.928	0.037	0.015	0.928	37.3	14.9	0.874	32.9	13.1	0.785	36.7	14.1
PP08072020_slice_73	0.927	0.038	0.015	0.927	37.9	15.4	0.873	33.2	13.5	0.779	37.4	14.8
PP08072020_slice_74	0.928	0.038	0.015	0.928	38.0	15.0	0.876	33.2	13.0	0.791	37.3	13.8
PP08072020_slice_75	0.930	0.038	0.016	0.930	37.6	16.3	0.878	32.1	14.2	0.780	36.9	15.9
PP08072020_slice_76	0.929	0.037	0.016	0.929	37.1	15.6	0.878	31.9	13.6	0.785	36.3	15.1
PP08072020_slice_77	0.924	0.037	0.016	0.924	37.1	16.0	0.874	32.8	14.3	0.785	36.4	15.6
PP08072020_slice_78	0.924	0.036	0.016	0.924	35.7	15.9	0.875	31.9	14.3	0.788	35.1	15.6
PP08072020_slice_79	0.931	0.033	0.014	0.931	33.3	14.0	0.883	29.9	12.4	0.803	32.6	13.0
PP08072020_slice_80	0.941	0.031	0.013	0.941	30.9	13.0	0.893	27.9	11.6	0.814	30.2	11.7
PP08072020_slice_81	0.940	0.031	0.014	0.940	31.0	13.6	0.895	28.2	12.3	0.804	30.5	13.0
PP08072020_slice_82	0.936	0.034	0.014	0.936	33.8	14.1	0.887	31.0	12.7	0.806	33.1	12.2
PP08072020_slice_83	0.920	0.041	0.017	0.920	40.5	16.6	0.870	38.0	15.1	0.780	40.0	15.6
PP08072020_slice_84	0.907	0.044	0.018	0.907	43.6	18.0	0.856	41.1	16.5	0.766	43.2	17.4
PP08072020_slice_85	0.905	0.044	0.018	0.905	44.1	17.9	0.849	41.6	16.5	0.758	43.7	17.3
PP08072020_slice_86	0.903	0.045	0.018	0.903	44.7	18.4	0.847	42.3	16.9	0.750	44.3	17.9
PP08072020_slice_87	0.898	0.047	0.019	0.898	46.6	19.2	0.839	44.0	17.6	0.740	46.2	18.5
PP08072020_slice_88	0.895	0.047	0.019	0.895	47.4	19.3	0.834	44.6	17.8	0.733	47.0	18.7
PP08072020_slice_89	0.897	0.047	0.019	0.897	46.8	19.1	0.834	44.0	17.7	0.730	46.4	18.5
PP08072020_slice_90	0.901	0.045	0.019	0.901	44.8	18.9	0.837	42.4	17.6	0.729	44.4	18.5
PP08072020_slice_91	0.906	0.043	0.018	0.906	43.5	18.1	0.842	41.3	17.0	0.734	43.0	17.4
PP08072020_slice_92	0.907	0.043	0.018	0.907	43.0	18.0	0.842	41.1	16.9	0.733	42.7	17.3
PP08072020_slice_93	0.904	0.044	0.019	0.904	43.6	18.8	0.838	41.9	17.7	0.722	43.3	18.5
PP08072020_slice_94	0.903	0.044	0.019	0.903	43.6	18.8	0.835	42.0	17.7	0.718	43.3	18.4
PP08072020_slice_95	0.899	0.044	0.019	0.899	43.9	18.8	0.830	42.5	17.8	0.714	43.6	18.3
PP08072020_slice_96	0.896	0.044	0.019	0.896	43.9	19.3	0.824	42.5	18.4	0.702	43.7	19.1
PP08072020_slice_97	0.894	0.044	0.020	0.894	44.0	19.6	0.819	42.4	18.5	0.694	43.8	19.3
PP08072020_slice_98	0.895	0.043	0.020	0.895	43.4	19.9	0.818	41.3	18.7	0.690	43.1	19.6
PP08072020_slice_99	0.900	0.042	0.020	0.900	41.9	20.4	0.820	39.8	19.2	0.685	41.6	20.2
PP08072020_slice_100	0.902	0.041	0.019	0.902	41.1	18.8	0.819	38.9	17.6	0.685	40.8	18.3
PP08072020_slice_101	0.897	0.043	0.020	0.897	42.5	20.0	0.815	39.7	18.7	0.678	42.2	19.7
PP08072020_slice_102	0.900	0.042	0.019	0.900	41.8	19.5	0.817	39.0	18.2	0.683	41.3	19.0
PP08072020_slice_103	0.901	0.041	0.019	0.901	41.3	19.2	0.817	38.6	18.0	0.686	40.8	18.5
PP08072020_slice_104	0.906	0.039	0.019	0.906	39.5	18.5	0.824	37.1	17.4	0.693	39.0	17.6
PP08072020_slice_105	0.913	0.037	0.018	0.913	37.2	17.8	0.835	35.1	16.6	0.701	36.8	17.4
PP08072020_slice_106	0.917	0.036	0.018	0.917	36.1	17.6	0.840	34.2	16.5	0.706	35.8	17.3
PP08072020_slice_107	0.917	0.036	0.017	0.917	35.7	17.4	0.840	33.9	16.4	0.706	35.4	17.1
PP08072020_slice_108	0.916	0.036	0.018	0.916	35.7	17.7	0.841	33.8	16.6	0.705	35.4	17.4
PP08072020_slice_109	0.914	0.036	0.018	0.914	36.4	17.6	0.838	34.4	16.5	0.706	36.1	17.1
PP08072020_slice_110	0.910	0.038	0.018	0.910	37.7	18.2	0.834	35.4	16.9	0.705	37.4	17.7
PP08072020_slice_111	0.910	0.037	0.018	0.910	37.0	18.1	0.832	35.0	16.9	0.702	36.8	17.8
